Ultra Fine Stainless Steel Screen Printing Wire Mesh

Ultra Fine Stainless Steel Screen Printing Wire Mesh
Ultra Fine Stainless Steel Screen Printing Wire Mesh Ultra Fine Stainless Steel Screen Printing Wire Mesh Ultra Fine Stainless Steel Screen Printing Wire Mesh Ultra Fine Stainless Steel Screen Printing Wire Mesh

Large Image :  Ultra Fine Stainless Steel Screen Printing Wire Mesh

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: FDA
Model Number: R&K-TH 98465
Payment & Shipping Terms:
Minimum Order Quantity: 50 meters
Price: negotiation
Packaging Details: Waterproof,woven bags inside,carton or plywood case outside.
Delivery Time: Within 8 work days
Payment Terms: L/C,T/T,Western Union,Paypal,Trade assurance
Supply Ability: 2000 square meter per month
Detailed Product Description
Product Name: 304 N 316 L 140 120 Micron Stainless Steel Screen Printing Wire Mesh / Netting Color: Silver
Weave Style: Plain Weave. Size: Usually 1.02meter*30meter Per Roll
Material: 304,316 Hole Size: 120 Micron
High Light:

stainless steel filter mesh

,

stainless steel mesh roll

Ultra Fine Stainless Steel Screen Printing Wire Mesh





Description of stainless steel screen mesh:



The weaving of metal mesh uses the technology of the textile industry. Fully automatic loom for metal, such as cloth weaving machines, using shuttles, spools and reels. As in a loom, lines running along the length of the web are called warps; they are wrapped around a harder crosshair or rod called a weft. Modern weaving machines can weave individual fibers with a thickness of less than 1 micron. The tufts or strands are made up of several woven fibers, cables or solid wires of various shapes, up to 5 mm thick. This kind of loom can produce nets up to 20 meters long and 8 meters wide. The woven mesh may be in the form of a flat or roll, which may be in a hard or soft form depending on the size of the wire used to make the mesh and the details of the mesh design.



Material SUS304,304L,316,316L
Hole Shape Square
Width 1.0-1.5m
size per roll usually 1meter or 1.2meter wide,30meter per roll
wire diameter Min diameter is0.018mm
aperture size Min is 1Micron



Stainless steel filter wire mesh refers to stainless woven wire mesh used in filter liquid,gas and pulp.The opening can be square, rectangular or special opening.Normally,this kind of wire mesh has standard opening sizes,uniform opening, good permeability and high strength. The raw materials should be chosen according to different environments of applications.



Features of stainless steel wire mesh:

  • Acid and alkali resistant
  • Corrosion resistant
  • Abrasion resistance, durable
  • Easy to plastic processing, so that the possibility of the use of stainless steel screens diversified
  • High finish, no surface treatment, maintenance is simple
  • Standard size,uniform opening,Precise control fiter rating etc





Application of stainless steel  mesh  roll :



Electronic display system
Solar and photovoltaic applications
Ultra-fine lines
Low temperature co-fired ceramic
Thick film microelectronics
Membrane switch circuit
Hybrid circuit
Microelectronics
Solder paste and adhesive



Specification:



Grid selection summary
The selected mesh type must be able to reproduce the minimum features of the artwork.
The ink used must be able to pass the selected mesh type without filtering.
The mesh ink film thickness obtained from the selected screen must be suitable for the application.



Mesh/inch Wire diameter (inch) Aperture (inch) Open area Weight (Sqaure meter
1*1 0.080 0.920 92.0 2.0
2*2 0.063 0.437 87.4 2.5
3*3 0.054 0.279 83.8 2.7
4*4 0.047 0.203 81.2 2.7
5*5 0.041 0.159 79.5 2.6
10*10 0.024 0.076 74.9 1.8
12*12 0.020 0.064 75.9 1.5
14*14 0.020 0.052 71.9 1.75
16*16 0.018 0.045 71.2 1.6
18*18 0.016 0.0398 69.4 1.4
20*20 0.009 0.041 76.0 0.57
30*30 0.012 0.0382 63.9 1.35
40*40 0.0098 0.015 72.1 1.25
50*50 0.0079 0.0121 36.7 1.0
60*60 0.0047 0.012 38.7 0.42
80*80 0.0047 0.0107 45.5 0.58
100*100 0.0039 0.006 59.8 0.50
120*120 0.0027 0.0056 67.7 0.29
150*150 0.0024 0.0043 41.6 0.27
165*165 0.0018 0.0043 50 0.167
180*180 0.0019 0.0036 64.5 0.22
200*200 0.0019 0.003 60.6 0.24
250*250 0.0012 0.0028 49.8 0.11
270*270 0.0014 0.0023 60 0.16
300*300 0.0012 0.0022 57 0.13
325*325 0.0014 0.0017 55.3 .0.20
400*400 0.0012 0.0013 52.7 0.18
500*500 0.0009 0.001 50.7 0.15
635*635 0.0007 0.0008 55.0 0.10

Ultra Fine Stainless Steel Screen Printing Wire Mesh 0Ultra Fine Stainless Steel Screen Printing Wire Mesh 1Ultra Fine Stainless Steel Screen Printing Wire Mesh 2
