7T - 165T Polyester Screen Printing With Stable Fabric Tension 100% Polyester Material

Large Image : 7T - 165T Polyester Screen Printing With Stable Fabric Tension 100% Polyester Material

Product Details:

Place of Origin:	Hebei, China (Mainland)
Brand Name:	R&K
Certification:	FDA / SGS / ISO:9001
Model Number:	R&K-Polyester mesh

Payment & Shipping Terms:

Minimum Order Quantity:	1 meter
Price:	Negotiable
Packaging Details:	Carton covered with woven bag;If you need a large quantity,wooden case.
Delivery Time:	7~15 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000 Meters per month

Contact Now

Detailed Product Description

Weave Type:	Plain	Material:	100% Polyester
Printing:	Polyester Screen Printing	Mesh Count:	18mesh-420mesh
Color:	White,yellow	Specification:	6T-165T
Thickness:	46-693um Printing Mesh	Thread Diameter:	31-350um
High Light:	polyester silk screen , polyester mesh screen

7T-165T Monofilament polyester screen printing mesh with stable fabric tension

Product Introduction

Polyester monofilament mesh is the most widely used screen printing mesh for textile, glass, ceramic, electronics and solar industries.

It provides excellent reproducible printing results and exceptional and accurate image quality and durability.

Additional, the wide ranges of mesh counts for different printing substrates can satisfy your most of printing requirements. 7T - 165T Polyester Screen Printing With Stable Fabric Tension 100% Polyester Material 0

Product characteristics

1. Screen printing not only can be monochrome printing, but also can be color register and screen color printing.

2. The Light Resistance of screen printing products is stronger than that of other kinds of printing products. It is more suitable for outdoor advertising and signage.

3. screen printing adaptability is very strong, wide range of applications.

4. screen printing can be a large area of printing, today's screen printing products up to a maximum range of 3 meters 4 meters, or more.

Product Specification

Mesh Count Diameter (Mesh/cm μm)	Mesh Count(Mesh/inch)	Weave	Aperture(μm)	Thread Diameter(μm)	Opening	Thickness
13-150PW(SL)	33	1:1	619	150	64	300
21-80PW(S)	55	1:1	296	80	69	120
21-150PW(SL)	55	1:1	326	150	46	260
24-100PW(T)	60	1:1	316	100	57	136
28-140PW(SL)	70	1:1	217	140	40	195
32-55PW(S)	81	1:1	257	55	67	103
32-64PW(S)	81	1:1	248	64	63	95
32-100PW(T)	81	1:1	212	100	45	165
36-90PW(T)	92	1:1	183	90	44	150
39-55PW(S)	100	1:1	177	55	56	88
40-80PW(T)	103	1:1	166	80	44	133
43-80PW(T)	110	1:1	149	80	41	130
47-45PW(S)	120	2:2	166	45*2	61	80
47-55PW(S)	120	1:1	152	55	51	88
48-70PW(T)	122	1:1	133	70	41	115
53-45PW(S)	135	2:2	143	45*2	57	79
53-55PW(S)	135	1:1	133	55	50	86
54-64PW(T)	137	1:1	115	64	39	100
54-70PW(HD)	137	1:1	109	70	35	116

Product Features

1.High durability and best tensility: all threads are the best domestic or imported.
2.Nice appearance, standard size: all are imported worldly advanced production lines from Switzerland.
3.Clean and never depigment
4. Faster turnaround time from the screen room to the pressroom
5. Good diathermancy
6. High air permeability

How to choose

specification	Usage
24T	Beach towels,Pennant inks,Giltter inks,Thicker inks
34T,36T,39T,43T	Textile inks,Opaque inks textile,T-shirts
49T,48T,54T,55T	Textile inks,Finer textile design,Water based inks
62T,64T,68T,72T	Enamel inks,Very fine textile ink or course plastisol ink printing
77T	Paper & Board inks & textile
90T,100T	Vinyl inks,Plastic inks,Plastisol inks,Solvent based
110T,120T,140T	Halftone printing,Paper & Board Vinyl Plastic
150T,165T	U.V. Printing,Or very fine halftone work,solvent inks
