120mesh Plain Weave Polyester Silk Screen Printing Mesh for t-shirt pringting
Product Details
Product name | 120mesh Plain Weave Polyester Silk Screen Printing Mesh for t-shirt pringting |
Mesh count | 18-420 mesh |
Color | White & Yellow |
Width | 127cm, 136cm, 145cm, 155cm, 158cm, 165cm |
Thread diameter | 31-200 Micron |
Mesh opening | 24-475 Micron |
Thickness | 55-365 Micron |
Material | 100% polyester |
Weave type | Plain weave |
Printing | Polyester screen printing |
Product Specification
Different mesh sizes are used for different applications in the screen printing process. Mesh size is measured by how many threads of mesh there are crossing per square inch. For instance, a 110 mesh screen has 110 threads crossing per square inch. The higher the mesh count, the finer the threads and holes are in the screen. The size of the mesh has a lot to do with how detailed your image is and how thick the ink you are using is. If you have an image with extremely high detail, a lower mesh screen wont hold the high detail.
Mesh Count | Weaving | Thread Diameter | Pening | Open Area | Tension |
um |
um | % | N/cm | ||
10T | 1:1PW | 250 | 740 | 53 | 60 |
12T | 1:1PW | 150 | 522 | 47 | 62 |
16T | 1:1PW | 200 | 435 | 47 | 48 |
16T | 1:1PW | 100 | 450 | 70 | 48 |
20T | 1:1PW | 100 | 410 | 68 | 49 |
24T | 1:1PW | 100 | 323 | 58 | 50 |
24T | 1:1PW | 120 | 303 | 51 | 48 |
27T | 1:1PW | 100 | 270 | 58 | 46 |
32T | 1:1PW | 71 | 230 | 60 | 28 |
32T | 1:1PW | 64 | 245 | 61 | 28 |
32T | 1:1PW | 100 | 200 | 43 | 42 |
36T | 1:1PW | 100 | 182 | 42 | 42 |
39T | 1:1PW | 55 | 199 | 61 | 32 |
39T | 1:1PW | 80 | 172 | 46 | 42 |
43T | 1:1PW | 80 | 151 | 43 | 36 |
47T | 1:1PW | 55 | 157 | 55 | 32 |
48T | 1:1PW | 71 | 141 | 44 | 32 |
53T | 1:1PW | 55 | 133 | 50 | 34 |
55T | 1:1PW | 55 | 126 | 49 | 32 |
55T | 1:1PW | 64 | 115 | 39 | 30 |
59T | 1:1PW | 55 | 101 | 42 | 33 |
64T | 1:1PW | 55 | 104 | 43 | 33 |
64T | 1:1PW | 64 | 95 | 36 | 35 |
72T | 1:1PW | 48 | 96 | 46 | 32 |
72T | 1:1PW | 55 | 80 | 30 | 32 |
77T | 1:1PW | 55 | 75 | 28 | 33 |
80T | 1:1PW | 48 | 78 | 30 | 29 |
90T | 1:1PW | 48 | 55 | 26 | 32 |
100T | 1:1PW | 40 | 58 | 32 | 27 |
110T | 1:1PW | 40 | 48 | 27 | 30 |
120T | 1:1PW | 34 | 45 | 30 | 26 |
120T | 1:1PW | 40 | 40 | 20 | 27 |
140T | 1:1PW | 34 | 32 | 19 | 31 |
150T | 1:1PW | 34 | 26 | 20 | 31 |
How to choose
20 and 40 mesh | glitter inks that need a very open mesh for printing. |
60 mesh | printing smaller glitter and most shimmer inks. |
80 mesh | printing shimmer inks and for laying down thick layers of ink for high-density printing |
110 mesh | makes printing white and other thick inks easy |
120 mesh | It works great for printing white ink and other colored inks that have a thicker viscosity. |
155 mesh | great for general purpose textile printing with basic to semi-fine detail |
200 mesh | It works very well with thinner inks and is a good middle-range mesh size. |
230 mesh | great for high-end fine detail printing. |
230 mesh | can hold halftones very well and also lets a little more ink through then a 305 mesh. |
280 mesh | great for high-end fine detail printing. |
305 mesh | holds extremely high detail, letting through only a thin layer of ink. This allows for a very soft hand on the garment and is great for use in printing halftones and process prints. |
Product Features
1.High durability and best tensility: all threads are the best domestic or imported.
2.Nice appearance, standard size: all are imported worldly advanced production lines from Switzerland.
3.Clean and never depigment
4. Faster turnaround time from the screen room to the pressroom
5. Good diathermancy
6. High air permeability
7. Acid resistance and Alkali resistance
8. Long working life & Hard wear
FAQ
1.Q: Are you trading company or manufacturer ?
A:We are a manufacturer-trading company integrating production and sales. We have more than 600 employees,more than 600 sets of production and testing equipment.
2.Q:Q: Do you have any certifications?
A:A: Yes, we have IS09001, FDA, ROSH, SGS to guarantee the product's quality, so you can totally truth us.
3.Q: Do you provide samples ?
A:We can provide samples to you for free but you have to pay the cost of freight.
4.Q: What is your terms of payment ?
A:A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
