0.5 1MM Stainless Steel Wire Mesh For Filtering And Clothing

Large Image : 0.5 1MM Stainless Steel Wire Mesh For Filtering And Clothing

Product Details:

Place of Origin:	Hebei,China
Brand Name:	R&K
Certification:	ISO9001:2008,SGS,FDA
Model Number:	R&K-SS

Payment & Shipping Terms:

Minimum Order Quantity:	1m
Price:	negotiation
Packaging Details:	Packing by rolls or folded then plastic bags inside carton or other packages according to the customers' demand.
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union,Paypal,Trade assurance.Credit card.
Supply Ability:	2000 square meter per month

Contact Now

Detailed Product Description

Material:	Stainless Steel 304 ,316	Weave Type:	Plain Weave,Twill Weave,Dutch Weave
Mesh Count:	1-400mesh	Width:	1m,1.2m
Color:	Silver	Application:	Filtration
High Light:	0.5mm Stainless Steel Wire Mesh , 1mm Stainless Steel Wire Mesh , 1.2m Stainless Steel Wire Mesh

Wear Resistance 0.5 1 MM Fine Stainless Steel Wire Mesh For Filtering And Clothing

Description of stainless steel wire mesh:

Material	SUS302, 304, 304L, 316, 316L, 310s
type	stainless steel wire,Stainless steel crimped wire mesh,Stainless steel crimped wire mesh
Width	1m,1.2m
Mesh Count	1mesh to 400 mesh
Feartures	rust-proof, corrosion-resistant, non-toxic, hygienic

The different is depends on the nickel content.

Nickel (Ni), the higher the content, the more corrosion-resistant, the worst is no nickel, which is basically equivalent to 201.
x nickel means the percentage of nickel in stainless steel. It is customary to think that nickel content "=8% stainless steel is 304 stainless steel

201----2Ni
302----4Ni
304----8Ni
316----10Ni
316L----12Ni

Features of stainless steel wire mesh:

Smooth surface
Anti-rust
preservative
Non-toxic
Hygienic and environmentally friendly

Heat-resistant,

Acid-resistant,

Corrosion-resistant

Wear-resistant

Application of stainless steel wire mesh :

Stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical and other industries, mainly for the filtration of gas and liquid and the separation of other media.

Hospitals, pasta, meat barbecues, living flower baskets, fruit baskets and other series are mainly made of stainless steel wire mesh, using electrolytic polishing technology for surface treatment, the surface is as bright as a mirror.

Specification of the stainless steel wire mesh:

Stainless steel mesh is classified according to species:

1. Stainless steel plain weave mesh.

2. Stainless steel twill mesh.

3. Stainless steel bamboo pattern net.

4. Five-shed stainless steel mesh.

5. Stainless steel punching net.

6. Stainless steel crimped wire mesh.

7. Stainless steel chain link fence.

8. Stainless steel expanded metal mesh.

9. Stainless steel welded wire mesh.

10. Stainless steel hexagonal net. 1

1. Stainless steel mat type net.

12. Stainless steel barbecue net.

13. Stainless steel mine screen.

14. Stainless steel tortoise shell net.

Mesh/Inch	Wire Diameter		Aperture		Open Area	Weight (kg/Square meter)
Mesh/Inch	Inch	MM	Inch	MM	Open Area	Weight (kg/Square meter)
1*1	0.08	2.03	0.92	23.37	92	2
2*2	0.063	1.6	0.437	11.1	87.4	2.5
3*3	0.054	1.37	0.279	7.09	83.8	2.7
4*4	0.047	1.19	0.203	5.16	81.2	2.7
5*5	0.041	1.04	0.159	4.04	79.5	2.6
10*10	0.025	0.64	0.075	1.91	74.9	2
12*12	0.02	0.508	0.063	1.6	75.9	1.5
14*14	0.02	0.508	0.051	1.3	71.9	1.8
16*16	0.018	0.457	0.445	1.13	71.2	1.6
18*18	0.017	0.432	0.386	0.98	69.4	1.6
20*20	0.02	0.24	0.03	0.76	76	0.56
20*20	0.016	0.33	0.034	0.86	72.2	1.1
30*30	0.12	0.305	0.213	0.54	63.9	1.4
30*30	0.0094	0.24	0.243	0.62	72.1	0.84
40*40	0.01	0.254	0.015	0.38	59.9	1.3
50*50	0.0055	0.14	0.0145	0.368	72.4	0.48
60*60	0.0047	0.12	0.012	0.303	71.6	0.42
60*60	0.0059	0.15	0.0107	0.273	64.5	0.65
80*80	0.0055	0.14	0.0069	0.117	45.5	0.76
100*100	0.0045	0.114	0.0055	0.14	55.1	0.59
100*100	0.004	0.102	0.006	0.152	59.8	0.49
120*120	0.0028	0.07	0.0057	0.147	67.7	0.29
150*150	0.0024	0.06	0.0043	0.11	64.7	0.26
150*150	0.0028	0.07	0.0039	0.1	58.8	0.38
165*165	0.0019	0.05	0.0041	0.104	67.5	0.2
180*180	0.0019	0.05	0.0035	0.091	64.5	0.22
180*180	0.0024	0.06	0.0031	0.081	57.4	0.32
200*200	0.0019	0.05	0.003	0.077	60.6	0.24
200*200	0.0024	0.06	0.0026	0.067	52.7	0.35
250*250	0.0016	0.04	0.0024	0.0616	60.6	0.2
270*270	0.0016	0.04	0.0021	0.054	57.4	0.21
300*300	0.0016	0.04	0.0018	0.045	53.5	0.23
325*325	0.0014	0.035	0.0017	0.0432	55.3	0.2
400*400	0.0012	0.03	0.0013	0.0335	52.7	0.18
500*500	0.0009	0.025	0.001	0.0258	50.7	0.15
635*635	0.0007	0.018	0.0008	0.022	55	0.1
