Product Details:
Payment & Shipping Terms:
|
Product: | PA66 Water Filtration Plain Weave Monofilament Nylon Filter Cloth | Hole Shape: | Square Hole |
---|---|---|---|
Usage: | Water Filtration | Weave Style: | Plain Woven Nylon Mesh |
Technique: | Woven | Feature: | Corrosion Resistance |
Grade: | PA66 | Type: | Filter Cloth |
Materila: | 100% Nylon | Width: | 1.27m , 1.45m ,1.65m |
High Light: | pa66 nylon filter mesh,pa66 nylon monofilament mesh,nylon filter mesh monofilament |
PA66 Wter Filtration Plain Weave Monofilament Nylon Filter Cloth
Product Introduction
Nylon screen, also known as nylon screen, nylon screen, nylon screen, is made of nylon 6 (PA6) monofilament woven by a flexible rapier loom, dyed (if necessary), and heat-set. It is made of chemical synthetic fibers and belongs to the polyamide series. Nylon wire mesh has high strength, good abrasion resistance, chemical resistance, water resistance, and elasticity. Because the wire diameter is uniform and the surface is smooth, the ink passability is also excellent. The disadvantage is that the stretchability of nylon mesh is relatively large. The tension of this kind of screen is reduced for a period of time after the screen is stretched, which makes the screen printing plate slack and reduces the accuracy. Therefore, it is not suitable for printing circuit boards that require high dimensional accuracy.
Product Specification
Fabric number | Mesh count | Thread diameter | Mesh opening | Opening | Thickness | Weight | |
No. | cm | inch | um | micron | % | um | g/m2 |
JPP4 | 4 | 10 | 550 | 1950 | 61 | 950 | 262 |
JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 | 271 |
JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 | 208 |
JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 | 186 |
JPP8 | 8 | 20 | 350 | 900 | 52 | 685 | 212 |
JPP9 | 9 | 24 | 250 | 861 | 60 | 455 | 145 |
JPP10 | 10 | 25 | 300 | 700 | 49 | 576 | 195 |
JPP12 | 12 | 30 | 250 | 583 | 49 | 470 | 162 |
12 | 30 | 300 | 533 | 41 | 585 | 234 | |
JPP14 | 14 | 35 | 250 | 464 | 42 | 470 | 190 |
JPP16 | 16 | 40 | 200 | 425 | 46 | 370 | 139 |
16 | 40 | 250 | 375 | 36 | 485 | 217 | |
JPP20 | 20 | 50 | 150 | 350 | 49 | 375 | 98 |
20 | 50 | 200 | 300 | 36 | 385 | 173 | |
JPP24 | 24 | 60 | 150 | 267 | 41 | 285 | 117 |
JPP28 | 28 | 70 | 120 | 237 | 44 | 215 | 87 |
JPP30 | 30 | 76 | 120 | 213 | 41 | 225 | 94 |
JPP32 | 32 | 80 | 100 | 213 | 46 | 165 | 69 |
JPP36 | 36 | 90 | 100 | 178 | 41 | 178 | 78 |
JPP40 | 40 | 100 | 100 | 150 | 36 | 190 | 87 |
JPP43 | 43 | 110 | 80 | 152 | 43 | 135 | 60 |
JPP48 | 48 | 120 | 80 | 128 | 38 | 145 | 62 |
JPP56 | 56 | 140 | 61 | 118 | 44 | 85 | 44 |
JPP59 | 59 | 150 | 61 | 109 | 41 | 98 | 46 |
JPP64 | 64 | 160 | 61 | 95 | 37 | 105 | 50 |
JPP72 | 72 | 180 | 50 | 89 | 41 | 82 | 39 |
JPP80 | 80 | 200 | 50 | 75 | 36 | 90 | 43 |
JPP100 | 100 | 250 | 43 | 57 | 32 | 65 | 35 |
JPP120 | 120 | 305 | 43 | 40 | 23 | 70 | 42 |
JPP130 | 130 | 330 | 43 | 34 | 20 | 75 | 45 |
JPP140 | 140 | 355 | 38 | 33 | 21 | 67 | 48 |
JPP150 | 150 | 380 | 38 | 29 | 19 | 68 | 51 |
JPP165 | 165 | 420 | 35 | 26 | 18 | 62 | 47 |
Product Application
Nylon filter mesh are widely used in:
Mining
Agriculture
Aquaculture
medical and laboratory.
infusion and transfusion filters
micro-aggregate filters
arterial and venous filters in oxygenator reservoirs and blood bag
Making nylon filter bags
Product Characteristic
Excellent abrasion resistance.
Excellent cake release.
Fine particle filtration.
Ideal for low temperature.
High tensile strength.
Good elasticity is ideal for continuous flexing purposes.
Suitable for caustic alkali atmosphere like dyestuffs.
Working temperature: 248 °F (constant); 275 °F (surge).
