Product Details:
Payment & Shipping Terms:
|
Material: | 100% Nylon | Color: | White Yellow |
---|---|---|---|
Mesh Count: | 305 Inch | Thread Diameter: | 43 Um |
Mesh Opening: | 40 Um | Thickness: | 70 Um |
High Light: | fda nylon filter cloth mesh,200 micron nylon filter cloth mesh,fda 200 micron nylon mesh |
It has the properties of acid resistance, alkali resistance, temperature resistance, abrasion resistance, etc.;
mainly used in mining, petroleum, chemical, food, medicine, Machinery manufacturing and other industries.
The filter is divided into textile fiber filter and metal filter.
The scale of the machine with the filter installed As a filter, it is used to filter natural water and food.
Appication of the nylon filter mesh roll:
Make nylon filter bags
Filter milk
Filter beer
Filter juice
Make filter piece
Screen printing
Features of thre nylon filter mesh roll:
High durability,
Beautiful appearance and standard size
Clean and never fade.
Fast turnaround time from the screen room to the newsroom
Good heat permeability.
High air permeability
Acid and alkali resistance.
long working life and wear resistance
Specification of the nylon filter mesh roll:
Fabric number | Mesh count | Thread diameter | Mesh opening | Opening | Thickness | |
No. | cm | inch | um | micron | % | um |
JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 |
JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 |
JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 |
JPP8 | 8 | 20 | 350 | 900 | 52 | 685 |
JPP9 | 9 | 24 | 250 | 861 | 60 | 455 |
JPP10 | 10 | 25 | 300 | 700 | 49 | 576 |
JPP12 |
12 | 30 | 250 | 583 | 49 | 470 |
12 | 30 | 300 | 533 | 41 | 585 | |
JPP14 | 14 | 35 | 250 | 464 | 42 | 470 |
JPP16 |
16 | 40 | 200 | 425 | 46 | 370 |
16 | 40 | 250 | 375 | 36 | 485 | |
JPP20 |
20 | 50 | 150 | 350 | 49 | 375 |
20 | 50 | 200 | 300 | 36 | 385 | |
JPP24 | 24 | 60 | 150 | 267 | 41 | 285 |
JPP28 | 28 | 70 | 120 | 237 | 44 | 215 |
JPP30 | 30 | 76 | 120 | 213 | 41 | 225 |
JPP32 | 32 | 80 | 100 | 213 | 46 | 165 |
JPP36 | 36 | 90 | 100 | 178 | 41 | 178 |
JPP40 | 40 | 100 | 100 | 150 | 36 | 190 |
JPP40 | 40 | 100 | 120 | |||
JPP43 | 43 | 110 | 80 | 152 | 43 | 135 |
JPP48 | 48 | 120 | 80 | 128 | 38 | 145 |
JPP56 | 56 | 140 | 61 | 118 | 44 | 85 |
JPP59 | 59 | 150 | 61 | 109 | 41 | 98 |
JPP64 | 64 | 160 | 61 | 95 | 37 | 105 |
JPP72 | 72 | 180 | 50 | 89 | 41 | 82 |
JPP80 | 80 | 200 | 50 | 75 | 36 | 90 |
JPP100 | 100 | 250 | 43 | 57 | 32 | 65 |
JPP120 | 120 | 305 | 43 | 40 | 23 | 70 |
