Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing

Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing
Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing

Large Image :  Faster Tension Monofilament Screen Printing Mesh Roll For T - Shirt Printing

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: ISO,SGS,FDA,
Model Number: R&K-LSY
Payment & Shipping Terms:
Minimum Order Quantity: 100square meter
Price: negotiation
Packaging Details: plastic bag inside,carton box outside
Delivery Time: 5days
Payment Terms: L/C, T/T, Western Union,Paypal,Trade asscurance. Credit Card.
Supply Ability: 30000meter within 2 months
Detailed Product Description
Brand Name: R&K Certification: ISO9001:2000,SGS,FDA,MSDS
Application: For T-shirt Printing Mesh Count: 140T/355 Mesh/inch
Thread Diameter: 30 Micron Weave Style: Plain Weave
High Light:

monofilament polyester screen fabric

,

monofilament nylon mesh

Faster Tension T-Shirt Monofilament Screen Printing Mesh For T-shirt Printing


Description For Monofilament Screen Printing Mesh:

Silk screen printing mesh are widely used in ceramic,glass,electonic components,textile,Garment,CD/DVD Pinting industry,like the life metal advertisement,business card,and the imgae..

Reking silk screen printing mesh be setting within 180-200 centigrate,we can control our temperature in filexibility. if you have any problem,you can contact us freely.the satable of the mesh depends on the temperature when setting up.


Brand name R&K
Certification ISO9001:2000,SGS,FDA,MSDS
Application For T-shirt Printing
Thread diameter 30 micron
Weave style Plain weave


Specification For Monofilament Screen Printing Mesh:


Mesh Count
Diameter
(Mesh/inch μm)
Mesh
Count
(Mesh
/Inch)
Weave Aperture
(μm)
Thread
Diameter
(μm)
Opening
(%)
Thickness(μm) Thickness
Tollerance
(+/- μm)
Theoretical
lnk(cm3/m2)
Weight
(g/m2)
13-150PW(SL) 33 1:1 619 150 64 300 14 128 60
21-80pw(S) 55 1:1 296 80 69 120 9 79 35
21-150PW(SL) 55 1:1 326 150 46 260 14 118 121
24-100PW(T) 60 1:1 316 100 57 136 11 65 81
28-140PW(SL) 70 1:1 217 140 40 195 13 76 125
32-55PW(S) 81 1:1 257 55 67 103 6 67 28
32-64PW(S) 81 1:1 248 64 63 95 6 56 32
32-100PW(T) 81 1:1 212 100 45 165 8 73 75
36-90PW(T) 92 1:1 183 90 44 150 8 65 68
39-55PW(S) 100 1:1 177 55 56 88 6 55 30
40-80PW(T) 103 1:1 166 80 44 133 7 59 60
43-80PW(T) 110 1:1 149 80 41 130 7 53 64
47-45PW(S) 120 1:1 166 45*2 61 80 6 42 40
47-55PW(S) 120 1:1 152 55 51 88 6 48 34
48-70PW(T) 122 1:1 133 70 41 115 6 47 55
53-45PW(S) 135 1:1 143 45*2 57 79 7 41 46
53-55PW(S) 135 1:1 133 55 50 86 6 42 40
54-64PW(T) 137 1:1 115 64 39 100 5 39 51
54-70(PW)HD 137 1:1 109 70 35 116 6 40 62
61-64PW(T) 155 1:1 90 64 31 101 5 30 58
64-55PW(S) 160 1:1 98 55 38 98 5 36 48
64-64PW(T) 160 1:1 85 64 30 115 6 34 61
68-55PW(S) 175 1:1 85 55 34 85 4 28 48
68-64PW(T) 175 1:1 78 64 28 105 5 30 65



Features For Monofilament Screen Printing Mesh:



1) Faster tensioning withour damage to threads;

2) Faster tension stabilization;

3) High elasticity;

4) Less tension loss during the stretching process;

5) High acid resistant,corrosion resistant;

6) Faster turnaround time from the screen room to the pressroom;
7) Improved registration due to stable tension;

8) Faster printing speeds.

Application For Monofilament Screen Printing Mesh:

Widely used in screen printing industry, filtering, textile printing and dyeing, printing plate, electronic printing, ceramics, glass printing and other industries.

Silk screen printing mesh can transfer thick ink deposits and great speical effect to make it to be optimal process to print high quality commercial farments,T-shirt etc.
Silk screen printing mesh can print the challenging intense color and ornate decor on glass and PCB etc.
