Product Details:
Payment & Shipping Terms:
|
Material: | 100% Polyester | Elasticity: | Low |
---|---|---|---|
Weave Type: | Plain Weave | Application: | Filter Water |
Product Name: | Polyester Screen Mesh | Feature: | High Tension |
Monofilament: | Yes | ||
High Light: | polyester filter fabric,polypropylene filter mesh |
High tension anti-static yellow and white 100% polyester monofilament mesh
Description of monofilament polyester screen mesh
The difference between polyester mesh and nylon mesh
Polyester---polyester fiber. It has good gas permeability and moisture wicking, as well as strong acid and alkali resistance and UV resistance.
nylon. Polyamide fiber. It has high strength, high wear resistance, high chemical resistance and good resistance to deformation and aging. It is hard to feel.
Polyester is a synthetic fiber derived from coal, air, water and petroleum. Polyester fibers were developed by a 20th century laboratory and formed by a chemical reaction between an acid and an alcohol. In this reaction, two or more molecules combine to form a macromolecule whose structure repeats over its entire length. Polyester fibers can form very stable and strong very ionic molecules.
Application of polyester filter mesh
Polyester mesh is widely used in
1. Air filter in air conditioning filter
2. Liquid filter for milk, juice, cheese, soy, etc.
3. Flour, solid mesh for grinding
We can drill down into filter bags, filter trays and filter filters.
Product Features
Polyester mesh has the following characteristics:
The tensile strength is small and the elasticity is strong. The single-wire mesh is suitable for printing integrated circuits, thick-film semiconductors, scale plates, counting plates and other high-precision printed materials; tensile strength, structural strength, resilience and printing durability are good; Sufficient chemical resistance, especially strong acid resistance, strong organic solvent resistance, recyclable like nylon; low hygroscopicity, almost unaffected by humidity; heat resistance higher than nylon; affected by ultraviolet light Nylon should be small.
Parameters of food grade polyester mesh
Fabric number | Mesh count | Thread diameter | Mesh opening | fabric thickness | weight | width | |
NO. | Cm mesh/inch | micron | micron | micron | g/m2 | inch | |
DPP5 | 5T | 13 | 450 | 1550 | 850 | 259 | 45,50 |
DPP6 | 6T | 15 | 400 | 1270 | 760 | 246 | 45,50 |
DPP7 | 7T | 18 | 350 | 1080 | 660 | 220 | 45,50 |
DPP8 | 8T | 20 | 350 | 900 | 660 | 251 | 45,50,62 |
DPP9 | 9T | 23 | 350 | 760 | 670 | 282 | 45,50,62 |
DPP10 | 10T | 25 | 300 | 700 | 570 | 231 | 45,50,62,65,72 |
DPP12 | 12T | 30 | 300 | 530 | 580 | 277 | 45,50,62 |
DPP14 | 14T | 36 | 200 | 515 | 360 | 143 | 45,50,72 |
DPP15 | 15T | 38 | 250 | 420 | 470 | 240 | 45,50,62,72 |
DPP16 | 16T | 41 | 200 | 425 | 380 | 164 | 45,50,62,72, |
DPP18 | 18T | 46 | 180 | 375 | 330 | 150 | 45,50,62,72, |
DPP19 | 19T | 48 | 150 | 375 | 260 | 110 | 45,50,62,72 |
DPP20 | 20T | 50 | 150 | 350 | 260 | 115 | 45,50,62,72 |
DPP21 | 21T | 53 | 150 | 325 | 270 | 121 | 45,50,62,72 |
DPP24 | 24T | 61 | 150 | 270 | 280 | 138 | 45,50,62,72 |
DPP27 | 27T | 68 | 120 | 250 | 230 | 100 | 45,50,62,72 |
DPP28 | 28T | 71 | 120 | 240 | 230 | 103 | 45,50,62,72 |
DPP29 | 29T | 74 | 120 | 225 | 230 | 107 | 45,50,62,72 |
DPP30 | 30T | 76 | 120 | 215 | 230 | 111 | 45,50,62,72 |
DPP34 | 34T | 86 | 100 | 195 | 180 | 87 | 45,50,62,72 |
DPP36 | 36T | 91 | 100 | 180 | 180 | 92 | 45,50,62,72 |
DPP39 | 39T | 99 | 64 | 190 | 115 | 40 | 45,50,62,72 |
DPP40 | 40T | 102 | 100 | 150 | 190 | 103 | 45,50,62,72 |
DPP43 | 43T | 110 | 80 | 150 | 155 | 71 | 45,50,62,72 |
Monofilament 100% polyester screen printing mesh bolting cloth | |
Weave type | plain wove |
Material | 100% polyester mesh |
Monofilament Style | Yes |
Width | 0.6-3.65m |
Mesh Count | 18-420 mesh/inch |
Thread Diameter | 27-350 micron |
Mesh Opening | 25-1068 micron |
Thickness | 46-693 micron |
Printing | polyester screen printing, silk screen printing |
Type | mesh fabric |
Elasticity | low |
