Low Elasticity SGS Monofilament PA66 Nylon Mesh Filter Fabric

Certification
China Hebei Reking Wire Mesh CO.,Ltd certification
China Hebei Reking Wire Mesh CO.,Ltd certification
I'm Online Chat Now

Low Elasticity SGS Monofilament PA66 Nylon Mesh Filter Fabric

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  Low Elasticity SGS Monofilament PA66 Nylon Mesh Filter Fabric

Product Details:
Place of Origin: HEBEI ,CHINA
Brand Name: R&K
Certification: MSDS,ROSH,SGS,ISO 9001
Model Number: R&K-Nylon mesh
Payment & Shipping Terms:
Minimum Order Quantity: 10 meters
Price: Negotiable
Packaging Details: 1.30-70m/roll in PVC bag 2 2-8 rolls per carton 3.waterproof bags outside 4.package belt strengthen
Delivery Time: 7~15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Meters per month
Detailed Product Description
Width: 1-3.65m Hole Shape: Square
Usage: Liquid Filter Weave Style: Plain Woven Nylon Mesh
Technique: Woven Feature: Corrosion Resistance
High Light:

SGS nylon mesh filter fabric

,

monofilament nylon mesh filter fabric

,

PA66 Nylon Mesh Filter Fabric

Food Grade 90Micron Nylon Filter Mesh Water And Oil Filtration Low Elasticity

Product Introduction

Micron nylon filter mesh is made of PA6 or PA66 monofilament yarn in plain weave or twill weave. It has smooth surface, uniform structure and ranges of mesh counts for industrial, medical and other filtration applications
This can have plain weave or double warp structure and can be used in Filtration, Screening, Sifting or Milling applications from the production of filter bags, and screens to being injection moulded as special filter applications.

Nylon filter cloth features the greatest abrasion resistance among the other three frequently used filter fabrics including polypropylene, polyester and cotton. It is often found in filtration applications of abrasive dusts and wet abrasive solids where abrasion resistance plays an important factor.


Product Specification



Material:100 % polyamide yarn
Mesh count: 200 mesh per inch
Mesh opening: 75 micron
Mesh range:13mesh - 500 mesh
Weave style of 200 mesh :plain weave
Color:white is popular,we also can make accept pink,purple color. custom-made is abailable.


Product Features

5–236 meshes for different filtration requirements.
Available for filter disc, filter tube, filter belt and filter bags.
Plain weave or twill weave options.
Excellent in liquid, powder, dust, gas and other element filtration.
Alternative to polyester (PA) filter mesh.


Product Application


Nylon filter mesh are widely used in:
Mining

Agriculture
Aquaculture
medical and laboratory.
infusion and transfusion filters
micro-aggregate filters
arterial and venous filters in oxygenator reservoirs and blood bag
Making nylon filter bags

Product Characteristic



Excellent abrasion resistance.
Excellent cake release.
Fine particle filtration.
Ideal for low temperature.
High tensile strength.
Good elasticity is ideal for continuous flexing purposes.
Suitable for caustic alkali atmosphere like dyestuffs.
Working temperature: 248 °F (constant); 275 °F (surge).

Product Features

It has high tension threshold and breaking point​
It has high modulus, low elongation monofilament nylon yarn
It has resist to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Good antistatic
No surface treatment



How to choose


Mesh Count is the number of threads per inch in the direction of warp and weft of the fabric.The mesh count is indentical in both warp and weft direction for Share Fitration's woven mesh.



Thread Diameter is specified as the diameter of the thread in microns.Yarn sizes in both warp and weft directions are the same.



Mesh Opening is the size or space between threads.The mesh opening is the result of the combination of the mesh count and yarn size.Mesh opening will determine the size or amount of material that will pass through the fabric.




Low Elasticity SGS Monofilament PA66 Nylon Mesh Filter Fabric 0
