3m 4m Wide Polyester Sludge Dewatering Mesh Belt With Steel Card Interface For Paper Mill
Product Introduce
The sludge dewatering mesh belt is mainly used for the sludge dewatering of sewage treatment plants. It has the characteristics of air permeability and water permeability, and is not permeable to sludge.
Due to its design structure, the sludge is easy to peel off after pressure filtration and is easy to clean. The net has a long life. This is a product specially designed for sludge dewatering.
Product Features
Hard-wearing
Flat surface
Good air permeability
Stable property against heat and moisture
Low thermal shrinking
Less elongation at heat
Long service life
Waterproof
Resistance under 180 degrees
Easy to clean
Unique structure help the solid granule get easily off the belt after filtration
Tear-resistance, shrink-resistance and abrasion resistance
Safe for food processing applications
High dimensional and diagonal stability,good air ventilation.
Seamless - the seam has exactly the same strength of the belt
Product Applications
Spiral belts are mainly used in filtration or separation applications for municipal projects for example waste water treatment, and various sludge belt press liquid filtration applications. Our products are suitable for most mechanical dewatering cases of various materials.
polyester spiral dryer belt is suitable for high-pressure pressfilter washer, horizontal belt washer, pulp-liquor separator and netting belt coal-washer.
polyester spiral dryer belt are extensively used for producing cardboard,kraft paper,corrugated paper,paper for train fare,single two-shed press-filter,instead of papermaking machine dry blanket,canvas,as well as apply to colliery,food and medicine as conveyor belts.
polyester spiral dryer belt are made with special first quality yarns in 100%polyester,every spiral link dryer fabric is heat-set granting a high degree of stability and long running life.
Material advantages
Advantages of our spiral belts are focusing on: strength, flat surface, good air permeability, stable property against heat and moisture, low thermal shrinking, less elongation at heat and a long lifespan.
Product Specification
| Model |
wire diameter
mm |
Density/cm |
Air Permeability
m3/m2h |
Weight
g/㎡ |
Tensile
kg/cm |
Application |
| Warp |
Weft |
Warp |
Weft |
| WNW14803 |
0.7 |
0.8 |
142 |
47-60 |
3900-
8500 |
1400 |
240 |
Sludge dewatering, fruit squeezing |
| WNW16803 |
0.7 |
0.8 |
156 |
46-50 |
6000 |
1400 |
265 |
Sludge dewatering, fruit squeezing |
| WNW16904 |
0.75 |
0.9 |
156 |
47 |
8000 |
1800 |
280 |
Sludge dewatering in the iron and steel industry |
| WNW121054 |
0.9 |
1.05 |
120 |
42 |
8000 |
1650 |
340 |
Sludge dewatering in the iron and steel industry |
| WNW22903 |
0.5 |
0.9 |
220 |
50-55 |
9000-
10000 |
1200 |
200 |
Dewatering of domestic sludge |
| WNW20703 |
0.5 |
0.7 |
200 |
70 |
10000 |
1000 |
185 |
Dewatering of domestic sludge |
| GW24504 |
0.5 |
0.5 |
240 |
130-140 |
8500-
10000 |
1180 |
220 |
Paper industry |
| WNW08903 |
0.9 |
0.9 |
78 |
50 |
8500 |
1430 |
210 |
Paper industry |
| WNW16704 |
0.7 |
0.7 |
160 |
90 |
12000 |
1350 |
265 |
Building Materials Industry |
