Softness Ptfe Conveyor Belt With ISO / SGS Certificate

China Hebei Reking Wire Mesh CO.,Ltd certification
China Hebei Reking Wire Mesh CO.,Ltd certification
I'm Online Chat Now

Softness Ptfe Conveyor Belt With ISO / SGS Certificate

small.img.alt small.img.alt

Large Image :  Softness Ptfe Conveyor Belt With ISO / SGS Certificate

Product Details:
Place of Origin: Hebei China
Brand Name: R&K
Certification: ISO9001:2008,SGS
Model Number: Y1819
Payment & Shipping Terms:
Minimum Order Quantity: 10 square meters
Price: negotiation
Packaging Details: Plastic bag+ bubble film+carton box
Delivery Time: within 10 days if we have in stock
Payment Terms: L/C, T/T, Western Union,Paypal,Trade assurance,Credit card.
Supply Ability: 1000 square meter per week
Detailed Product Description
Material: Fiberglass And Kevlar Material Usage: Transport And For Drying
Standard Size: 1*1,2*2,4*4mesh,10*10mesh Product Name: Teflen Mesh Conveyor Belt
Place Of Original: Hebei,China Certifiation: ISO,SGS
High Light:

Softness Ptfe Conveyor Belt


Ptfe Conveyor Belt With ISO


Ptfe Conveyor Belt With SGS

Food Grade Opening Size teflen Mesh Conveyor Belt For Screen Mesh Printing



Introduce of the teflen conveyor belt:


teflen mesh conveyor belt is mainly used in screen printing to transport imprinted material through drying oven and cooling chambers.This belt have a long lasting perform well over a wide range of operating temperatures.

teflen mesh conveyor belt can supply a wid variety of splice and edge reinforcement in order to rebound client's specific application.


Standard size: 1×1mm.2×2mm,4×4mm,10×10mm,0.5×1mm,2×2.5mm

Material: fiberglass and kvelar glass.

Weight: 370g/m2-600g/m2

Max width: 6 meters


Recommended Application of the teflen  conveyor belt:


External wall thermal insulation

teflen conveyor belt is woven by fiberglass yarn as its basis fabric,the coated by alkaline resistant latex,it has a feature of fine alkaline-resistance,high tensile strength of warp and woof.


Features of the teflen conveyor belt:


1) Safe and non-toxic-in line with the United Stated FDA,Germany LFGB food inspection standards.

2) High and low temperature in the range of -140℃-250℃ safe use.

3) Non-adhesive-permanent stick will not lose the anti-sticking performance due to wear.

4) Strong and durable-up to 2000times, the number of re-ues,long life from the internal high-strength fiberglass fabric.

5) Super adsorption of various material can be absorbed on the console,is ideal for kenading table.

6) Easy to clean-wipe with water of cloth light rub,stubborn stains can be used as long as ordinary brush light brush.

7) Storage easy-can be rolled up when no in use,do not take up space.


Advantages of the teflen conveyor belt:


Softness, and easy use



specification for the teflen mesh conveyor belt:


Material Dimension Weight Thickness Tensile strength
Fiberglass 1mm×1mm 370g/m2 0.5mm 310/290 N/CM
Fiberglass 2mm×2mm 450g/m2 0.7mm 350/310 N/CM
Fiberglass 4mm×4mm 400g/m2 1.0mm 390/320 N/CM
Fiberglass 4mm×4mm 450g/m2 1.0mm 390/320 N/CM
Kevlar glass 4mm×4mm 600g/m2 1.2mm 895/370 N/CM
Fiberglass 4mm×4mm 500g/m2 1.0mm 395/370 N/CM
Kevlar glass 4mm×4mm 500g/m2 1.0mm 900/600 N/CM
Fiberglass 4mm×4mm 550g/m2 1.0mm 395/370 N/CM
Fiberglass 10mm×10mm 450g/m2 1.2mm 360/300 N/CM
Fiberglass 0.5mm×1mm 420g/m2 0.5mm 310/290 N/CM
Fiberglass 2mm×2.5mm 600g/m2 0.9mm 390/320 N/CM



Photo of the teflen mesh conveyor belt:


Softness Ptfe Conveyor Belt With ISO / SGS Certificate 0


Shipping: By courier, air,sea. if you need more, we can ship by ocean,


Packing: platic bag + carton box. or as your request.
