Screen Printing Mesh & Filter Mesh With Stainless Steel ,Polyester and Nylon Material.Screen Printing Material

Home ProductsSilk Screen Printing Mesh

Monofilament Polyester Mesh

China Hebei Reking Wire Mesh CO.,Ltd certification
China Hebei Reking Wire Mesh CO.,Ltd certification
I'm Online Chat Now

Monofilament Polyester Mesh

Monofilament Polyester Mesh
Monofilament Polyester Mesh Monofilament Polyester Mesh Monofilament Polyester Mesh Monofilament Polyester Mesh

Large Image :  Monofilament Polyester Mesh

Product Details:
Place of Origin: HEBEI ,CHINA
Brand Name: R&K
Certification: MSDS,ROSH,SGS,ISO 9001
Model Number: R&K-Polyester mesh
Payment & Shipping Terms:
Minimum Order Quantity: 10 meters
Price: Negotiable
Packaging Details: 1.30-70m/roll in PVC bag 2 2-8 rolls per carton 3.waterproof bags outside 4.package belt strengthen
Delivery Time: 7~15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Meters per month
Detailed Product Description
Weave Type: Plain Monofilament Style: Yes
Width: 0.6M-3.6M Application: Screen Printing
Mesh Opening: 25-1068um Printing Mesh Thickness: 46-693um Printing Mesh
High Light:

silk screen fabric mesh


silk screen mesh roll


Plain Weave Yellow 200 Micron Monofilament Polyester Silk Screen Printing Mesh

Product Introduction


Material 100% polyester
Thickness 55-365 Micron
opening size 100micron
Leadtime 2-10 days according to the order quantity
Sample Avalibale
width 115cm,127cm,136cm,145cm,157cm,165cm,188cm,220cm and MAX width can be 3.65cm


Screen printing is a modern printing method popular for making T-shirts and other garments, but also widely used for Textile Printing, Ceramic Printing, Glass Printing, Graphics Printing, Electronic Printing, CD/DVD Printing, Wood printing, Metal printing, Plastic and leather printing.


Product Feature


1. Polyester printing screen has the characteristics of high tension threshold and breaking point

2. Polyester printing screen belongs to high modulus, low elongation monofilament polyester yarn

3. Polyester printing screen can resist chemicals, abrasion, heat and moisture

4. It is in minimal tension loss during stretching process

5. It improved registration due to stable fabric tension

6. Polyester printing mesh has the ability of good antistatic

7. Polyester printing mesh does not have many cumbersome surface treatments


Product Application


1. Printing mesh for Textile

    Printing mesh for T-shirt/Garment

Printing mesh for Flatbed Textile
Printing mesh for High-end Textile
2. Printing mesh for Electronics
  Printing mesh for Printed Circult BoardsPrinting mesh for Membrane Switches
3. Printing mesh for Glass
Pharmacy Glass Appliance Printing
Home Appliance Printing
Automotive Glass Printing
Glass Containers Printing
4. Printing mesh for Ceramics
5. Printing mesh for CDs/DVDs
Product Specification
Mesh Count Diameter (Mesh/cm μm) Mesh Count(Mesh/inch) Aperture(μm) Thread Diameter(μm)
13-150PW(SL) 33 619 150
21-80PW(S) 55 296 80
21-150PW(SL) 55 326 150
24-100PW(T) 60 316 100
28-140PW(SL) 70 217 140
32-55PW(S) 81 257 55
32-64PW(S) 81 248 64
32-100PW(T) 81 212 100
36-90PW(T) 92 183 90
39-55PW(S) 100 177 55
40-80PW(T) 103 166 80
43-80PW(T) 110 149 80
47-45PW(S) 120 166 80
47-55PW(S) 120 152 55
48-70PW(T) 122 133 70
53-45PW(S) 135 143 45*2
53-55PW(S) 135 133 70
54-64PW(T) 137 115 64
54-70PW(HD) 137 109 70
61-64PW(T) 155 90 64
64-55PW(S) 160 98 55
64-64PW(T) 160 85 64
68-55PW(S) 175 85 55
68-64PW(T) 175 78 64
72-48PW(S) 182 90 48
72-55PW(T) 182 85 55
77-48PW(S) 195 77 48


Product weaving


The most common weaving pattern in Plain screen printing mesh is called "plain weave" and will be designated on labels as "PW." It is a simple over-and-under weaving pattern. "Twill weave (TW)" is used to create thicker, sturdier screens and relies on complex patterns of weaving, which vary depending on the manufacturer. Twill weave mesh will be thicker than plain weave even if the mesh count is identical. The Screen Printing Technical Foundation compared the different weave's performance and found that twill weave transferred somewhat less ink than plain weave.


Monofilament Polyester Mesh 0
