High Strength Dutch Woven Square Hole 70x600 Ss 304 Wire Mesh

High Strength Dutch Woven Square Hole 70x600 Ss 304 Wire Mesh
High Strength Dutch Woven Square Hole 70x600 Ss 304 Wire Mesh High Strength Dutch Woven Square Hole 70x600 Ss 304 Wire Mesh

Large Image :  High Strength Dutch Woven Square Hole 70x600 Ss 304 Wire Mesh

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: SGS
Model Number: Dutch-09
Payment & Shipping Terms:
Minimum Order Quantity: 1 squaremeter
Price: Negotiate
Packaging Details: Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 1000 squaremeter per week
Detailed Product Description
Material: Stainless Steel Wire Mesh Type: Weave Wire Mesh
Hole Shape: Square Shape Application: Screen
Technique: Woven Feature: Fuel Filter
Product Name: Dutch Mesh
High Light:

SGS ss 304 wire mesh

,

70x600 ss 304 wire mesh

,

304 stainless steel woven wire mesh

High strength 304 material stainless steel dutch woven wire mesh



Description of stainless steel Dutch woven wire mesh



Ordinary Dutch woven mesh is made by weaving closed and warp threads of different diameters. Our wires have a small micron diameter and are woven with larger diameter warp threads. Our wire is tightly woven to produce a high-strength mesh while allowing

The thinner wires are in microns and are tightly woven together to provide a tight wire mesh for the filtering operation. Larger wires strengthen the mesh. Ordinary Dutch woven wire mesh is used to filter and separate liquids and slurries.



Application of stainless steel Dutch wire mesh



Dutch wire mesh has endless applications in industry, commerce and decoration. Such as filters, sieves, separators, filters, baskets, gas diffusion, drying, car grill nets, vents, building and construction nets, craft paper, decorative nets, fan hoods, filtering liquids and gases, fireplace screens, food Dry, basic ventilation net, gutter protection net, high transparent net, hydraulic filter, insect net, lampshade, oil filter, pest control, safety, separation of fuel from water



Feature of the stainless steel Dutch wire mesh



1. High precision
2. The warp is larger than the diameter
3. The wefts may be close to each other
4. No pressure loss or no pressure loss during filtration
5. Highest filter surface
6. More stable than square and rectangular wire mesh



Parameters of stainless steel Dutch mesh



Plain weave Dutch mesh

Number

Mesh(warpxweft)

Wire diameter

(warpxweft)

Aperture

(um)

Weight

(kg/m2)

32#

8 x 62

0.63mm x 0.45mm

300

5.42

40#

10 x 79

0.50mm x 0.355mm

250

3.16

48#

12 x 64

0.58mm x 0.40mm

280

2.9

55#

14 x 88

0.40mm x 0.30mm

180

2.54

76#

19 x 140

0.315mm x 0.20mm

140

1.88

80#

20 x 300

0.35mm x 0.20mm

-

3.6

95#

24 x 110

0.355mm x 0.25mm

120

2.45

100#

25 x 140

0.28mm x 0.20mm

100

1.95

120#

30 x 150

0.25mm x 0.18mm

80

1.68

140#

35 x 175

0.224mm x 0.16mm

71

1.52

160#

40 x 200

0.20mm x 0.14mm

60

1.40

180#

45 x 250

0.16mm x 0.112mm

56

1.09

200#

50 x 250

0.14mm x 0.11mm

53

1.04

220#

55.5 x 280

0.14mm x 0.10mm

50

0.92

240#

65 x 330

0.11mm x 0.08mm

36

0.71

280#(1)

70 x 350

0.11mm x 0.08mm

35

0.72

280#(2)

70 x 385

0.11mm x 0.07mm

32

0.75

300#

78 x 700

0.11mm x 0.08mm

30

1.39

315#(1)

80 x 400

0.10mm x 0.065mm

40

0.62

315#(2)

80 x 600

0.10mm x 0.06mm

-

0.74

315#(3)

80 x 800

0.15mm x 0.04mm

-

0.77

320#

81 x 780

0.10mm x 0.07mm

30

1.22

354#

90 x 550

0.12mm x 0.05

-

0.667

Width:1m-1.6m
