Product Details:
Payment & Shipping Terms:
|
Colour: | White,Yellow | Material: | 100% Polyester |
---|---|---|---|
Weave Type: | Plain | Length: | 50M/roll,100M/roll |
Elasticity: | Low | Mesh Count: | 80 Mesh/inch |
Highlight: | nylon mesh screen roll,silk screen roll |
Polyester Screen Mesh Roll Printing on Glass Plate DPP120 /300-314
Description of polyester screen mesh roll printing on glass plate:
Model Number | DPP77/195-55 |
Mesh Count |
30-460M/inch
|
Product Name | Polyester Screen Mesh Roll Printing on Glass Plate DPP120 /300-314 |
Main customers | BYD,SEFAR,FUYAO,FOXCONN |
Polyester Printing Mesh | |||||||
Model | Specification (/cm) | Mesh count (mesh/inch) | Thread Diameter (um) | Mesh opening(um) | Open Area(%) | Thickness(um) | Theoretic Ink Volume (cm3/m2) |
PET36/169 | 36 | 90 | 100 | 169 | 39 | 170 | 66 |
PET39/168 | 39 | 99 | 80 | 168 | 45 | 136 | 62 |
PET39/149 | 39 | 99 | 100 | 149 | 35 | 170 | 60 |
PET43/145 | 43 | 110 | 80 | 145 | 41 | 136 | 56 |
PET47/135 | 47 | 120 | 71 | 135 | 42 | 121 | 51 |
PET51/119 | 51 | 130 | 71 | 119 | 39 | 121 | 47 |
PET53/112 | 53 | 135 | 71 | 112 | 37 | 121 | 45 |
PET100/51 | 100 | 250 | 40 | 51 | 30 | 85 | 26 |
PET110/48 | 110 | 280 | 34 | 48 | 33 | 58 | 19 |
PET110/43 | 110 | 280 | 40 | 43 | 26 | 68 | 18 |
PET120/44 | 120 | 305 | 31 | 44 | 33 | 53 | 18 |
PET120/42 | 120 | 300 | 34 | 42 | 29 | 58 | 17 |
PET120/37 | 120 | 300 | 40 | 37 | 18 | 68 | 13 |
PET130/31 | 130 | 330 | 40 | 31 | 17 | 68 | 12 |
PET130/36 | 130 | 330 | 34 | 36 | 26 | 58 | 15 |
PET140/34 | 140 | 350 | 31 | 34 | 25 | 53 | 13 |
PET140/32 | 140 | 350 | 34 | 32 | 19 | 58 | 11 |
PET150/34 | 150 | 380 | 27 | 34 | 30 | 46 | 14 |
PET150/31 | 150 | 380 | 30 | 31 | 23 | 51 | 12 |
PET150/28 | 150 | 380 | 34 | 28 | 16 | 58 | 9 |
PET165/29 | 165 | 420 | 27 | 29 | 22 | 46 | 10 |
PET165/25 | 165 | 420 | 31 | 25 | 16 | 53 | 8 |
Remark:The above are theoretic data for reference only.Thickness error range±5% ;Mesh Opening & Open Area & Theoretic Ink Volume only slight error according to actual data. |
More Specifications kindly please contact us.(8T~165T)
