Monofilament Polyester Silk Screen Printing Mesh Roll

China Hebei Reking Wire Mesh CO.,Ltd certification
China Hebei Reking Wire Mesh CO.,Ltd certification
I'm Online Chat Now

Monofilament Polyester Silk Screen Printing Mesh Roll

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Monofilament Polyester Silk Screen Printing Mesh Roll

Product Details:
Place of Origin: HEBEI ,CHINA
Brand Name: R&K
Certification: MSDS,ROSH,SGS,ISO 9001
Model Number: R&K-Polyester mesh
Payment & Shipping Terms:
Minimum Order Quantity: 50 meters
Price: Negotiable
Packaging Details: 1.30-70m/roll in PVC bag 2 2-8 rolls per carton 3.waterproof bags outside 4.package belt strengthen
Delivery Time: 7~15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Meters per month
Detailed Product Description
Weave Type: Plain Material: 100% Polyester
Mesh Count: 18mesh-420mesh Length: 30-70m/roll
Usage: Screen Prinitng Packaging: Roll On Paper Scroll
High Light:

nylon mesh screen roll


silk screen roll

Reusable Monofilament Polyester Silk Screen Printing Mesh Roll Textile Mesh

Product Introduction


Polyester Screen Printing Mesh It is a type of woven polyester which is extracted from yarn by using a particular mechanism of heating of the polyester. Thus, the heater form is made in a single filament threaded form. The extruded form of thread filament is the manufactured and is spun according to the required diameter.

Screen printing is a modern printing method popular for making T-shirts and other garments, but also widely used for Textile Printing, Ceramic Printing, Glass Printing, Graphics Printing, Electronic Printing, CD/DVD Printing, Wood printing, Metal printing, Plastic and leather printing.


Product Aapplication


1 . Polyester printing mesh can be applied to T-shirt, clothing printing

2 . Polyester printing mesh can be applied to High-end textile printing

3 . Polyester printing mesh can be used for pharmacy glass appliance printing

4 . Polyester printing mesh for Ceramics

5 . Polyester printing mesh for CDs/DVDs


Product Features


1 . Polyester printing screen has the characteristics of high tension threshold and breaking point

2 . Polyester printing screen can resist chemicals, abrasion, heat and moisture

3 . It improved registration due to stable fabric tension

4 . Polyester printing mesh does not have many cumbersome surface treatments


Product Specification



Mesh Count Diameter (Mesh/cm μm) Mesh Count(Mesh/inch) Aperture(μm) Thread Diameter(μm)
13-150PW(SL) 33 619 150
21-80PW(S) 55 296 80
21-150PW(SL) 55 326 150
24-100PW(T) 60 316 100
28-140PW(SL) 70 217 140
32-55PW(S) 81 257 55
32-64PW(S) 81 248 64
32-100PW(T) 81 212 100
36-90PW(T) 92 183 90
39-55PW(S) 100 177 55
40-80PW(T) 103 166 80
43-80PW(T) 110 149 80
47-45PW(S) 120 166 80
47-55PW(S) 120 152 55
48-70PW(T) 122 133 70
53-45PW(S) 135 143 45*2
53-55PW(S) 135 133 70
54-64PW(T) 137 115 64
54-70PW(HD) 137 109 70
61-64PW(T) 155 90 64
64-55PW(S) 160 98 55
64-64PW(T) 160 85 64


Product Details


The most common weaving pattern in Plain screen printing mesh is called "plain weave" and will be designated on labels as "PW." It is a simple over-and-under weaving pattern. "Twill weave (TW)" is used to create thicker, sturdier screens and relies on complex patterns of weaving, which vary depending on the manufacturer. Twill weave mesh will be thicker than plain weave even if the mesh count is identical. The Screen Printing Technical Foundation compared the different weave's performance and found that twill weave transferred somewhat less ink than plain weave.

Monofilament Polyester Silk Screen Printing Mesh Roll 0
