316 Thin 400 Mesh Stainless Steel Screen Printing Mesh For Colour Half-tone Screen Printing
Description of stainless steel screen mesh:
Stainless steel printing screen refers to the stainless steel screen used for printing. The opening is a square mesh with uniform pore size. Generally, this screen has a standard opening size, uniform opening, good permeability and high opening ratio. strength. Raw materials should be selected according to different application environments.
| Material |
SUS304,304L,316,316L |
| Hole Shape |
Square |
| Width |
1.0-1.5m |
| size per roll |
usually 1meter or 1.2meter wide,30meter per roll |
| wire diameter |
Min diameter is0.018mm |
| aperture size |
Min is 1Micron |
Stainless steel filter wire mesh refers to stainless woven wire mesh used in filter liquid,gas and pulp.The opening can be square, rectangular or special opening.Normally,this kind of wire mesh has standard opening sizes,uniform opening, good permeability and high strength. The raw materials should be chosen according to different environments of applications.
Features of stainless steel wire mesh:
- Acid and alkali resistant
- Corrosion resistant
- Abrasion resistance, durable
- Easy to plastic processing, so that the possibility of the use of stainless steel screens diversified
- High finish, no surface treatment, maintenance is simple
- Standard size,uniform opening,Precise control fiter rating etc
Application of stainless steel mesh roll :
The main application of screen printing is to print solid objects with 3D quality. These applications typically use mesh sizes of 77 threads per inch or higher, and include products such as bottles, containers, and advertising materials. However, when printing ceramic tiles and decals to be used on ceramics and glass, nylon screen printing is also an excellent choice. For any of these applications, the elasticity of the nylon screen printing screen is particularly high, enabling excellent printing results even on the most difficult surfaces
Commercial applications:
Posters, billboards, POPs, display stands, stickers, signs, flags
daily supplies:
Toys, stationery, sporting goods, luggage, T-shirts, cosmetic containers, cosmetic containers, packaging, wooden products, glass, ceramics.
Industrial applications:
Automotive instruments, CDs, electrical parts, membrane switches, liquid crystal displays (LCD), vending machines, nameplates, printed circuit boards, thick ICs.
Specification:
| Specification |
Mesh/
inch |
Wire Dia
(μm) |
Open area
Ratio(%) |
Apereture
(μm) |
Apereture
(μm) |
Calendered Thickness
(μm) |
Theoretical
lnk(cm^/m^) |
| 40×40×160 |
40 |
160 |
56 |
475 |
300-320 |
As order |
179.1 |
| 60×60×120 |
60 |
120 |
51.3 |
303 |
230-245 |
As order |
123.2 |
| 80×80×120 |
80 |
120 |
39 |
198 |
235-245 |
As order |
92.9 |
| 80×80×90 |
80 |
90 |
52 |
228 |
175-180 |
As order |
103 |
| 100×100×100 |
100 |
100 |
36.8 |
154 |
195-205 |
As order |
77.2 |
| 120×120×80 |
120 |
80 |
39 |
132 |
155-165 |
As order |
65.8 |
| 150×150×60 |
150 |
60 |
41.7 |
109 |
115-124 |
As order |
50 |
| 165×165×35 |
165 |
35 |
60 |
119 |
70-75 |
As order |
48 |
| 165×165×45 |
165 |
45 |
50.1 |
109 |
88-93 |
As order |
45.1 |
| 165×165×50 |
165 |
50 |
45.6 |
104 |
97-105 |
As order |
45.6 |
| 180×180×50 |
180 |
50 |
42 |
91 |
98-104 |
As order |
41.7 |
| 200×200×40 |
200 |
40 |
46.9 |
87 |
82-84 |
As order |
43 |
| 200×200×50 |
200 |
50 |
37 |
77 |
98-103 |
As order |
42 |
| 230×230×35 |
230 |
35 |
46.7 |
75 |
72-76 |
50-67 |
37 |
| 250×250×30 |
250 |
30 |
49.7 |
72 |
64-68 |
40-58 |
30 |
| 250×250×35 |
250 |
35 |
43 |
67 |
76-78 |
57-70 |
32 |
| 270×270×35 |
270 |
35 |
39.4 |
59 |
76-80 |
58-70 |
30 |
| 300×300×30 |
300 |
30 |
41.7 |
55 |
66-68 |
4-59 |
28 |
| 325×325×30 |
325 |
30 |
38 |
48 |
66-68 |
45-60 |
24 |
| 325×325×28 |
325 |
28 |
41.2 |
50 |
63-64 |
40-56 |
26.4 |
| 325×325×23 |
325 |
23 |
49.8 |
55 |
49-53 |
37-41 |
25.4 |
| 350×350×35 |
350 |
25 |
43 |
48 |
52-54 |
41-50 |
18.7 |
| 400×400×23 |
400 |
23 |
40.7 |
41 |
50-54 |
35-48 |
19 |
| 500×500×18 |
500 |
18 |
41.7 |
33 |
36-40 |
23-29 |
15.3 |
