Food Grade High Tension Nylon Material 40 100 120 1000 Micron Filter Mesh Flour Sieve Mesh
Product Introduction
Material:FDA food grade commercial nylon mesh
Mesh opening:5-1950 micron
Weave Style:Plain Weave
Thread Diameter:31-550 micron
Monofilament Style:Yes
Thickness:51-1100 micron
Hole Shape:square
Roll length:30-70m or customized
Roll width:1m, 1.25m, 2.5m, 2.95m or customized
Usage:liquid filter, air filter, dust filter
Type:filter mesh, filter cloth, mine sieving mesh, filter disc, filter cylinder
Product description
Nylon mesh is a chemical fiber woven mesh made of chemical fibers such as nylon, polyester, and nanofiber as raw materials, and is machined by wire mesh. Nylon is resistant to high temperature and alkali, and polyethylene is resistant to acid , Nylon mesh is the general term for these chemical fiber woven mesh. Nylon mesh include: (nylon blends,) nylon mesh, polyethylene mesh, and sunshade mesh..
Nylon filter mesh fabric is widely used in filteration(water,flour,nut milk,soybean milk,juice,oil,cheese,air purification,power coating filtering in industry etc).printing and dyeing, the industries of petroleum, chemical, metallurgy, cement, environmental dedusting etc.
Product Property
Temperature : working temperature under 150℃
Chemicals: Acid resistance and Alkali resistance
Safe Grade : food grade
Mesh count:the number of threads per inch in the direction of warp and weft of the fabric.The mesh count is indentical in both warp and weft direction for Share Fitration's woven mesh.
Thread Diameter:specified as the diameter of the thread in microns.Yarn sizes in both warp and weft directions are the same.
Mesh Opening:the size or space between threads.The mesh opening is the result of the combination of the mesh count and yarn size.Mesh opening will determine the size or amount of material that will pass through the fabric.
Product Features
It has high tension threshold and breaking point
It has high modulus, low elongation monofilament nylon yarn
It has resist to chemicals, abrasion, heat and moisture
It can achieve Minimal tension loss during stretching process
Good Improved registration due to stable fabric tension
It has Good antistatic
No surface treatment, can be customized according to customer requirements
Product Advantage
| They have good acid resistance and alkali resistance and are not easily corroded |
| Due to their uniformity they can be woven with great precision to give exact and regular apertures |
| The resulting material has a very smooth surface so that the filtered particles will easily separate from it |
| They have great strength and elasticity |
| Due to different pore sizes, they can be used in different filtration systems and can be well adapted to each industry. |
| Because the aperture can be made small, it has ultra-high precision. Can be adapted to all filtering applications |
| Has good antistatic properties |
Product Package
1. We always use poly bag for the goods which ship by air, so that customer can save freight free
2. Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping
3. There also have some customer request us to use the carton to packing their goods
4. We can according to customer's requirements
