Screen Printing Mesh & Filter Mesh With Stainless Steel ,Polyester and Nylon Material.Screen Printing Material

Home ProductsNylon Filter Mesh

30m/Roll Plain Weave 1.25m Nylon Filter Mesh

China Hebei Reking Wire Mesh CO.,Ltd certification
China Hebei Reking Wire Mesh CO.,Ltd certification
I'm Online Chat Now

30m/Roll Plain Weave 1.25m Nylon Filter Mesh

30m/Roll Plain Weave 1.25m Nylon Filter Mesh
30m/Roll Plain Weave 1.25m Nylon Filter Mesh 30m/Roll Plain Weave 1.25m Nylon Filter Mesh 30m/Roll Plain Weave 1.25m Nylon Filter Mesh

Large Image :  30m/Roll Plain Weave 1.25m Nylon Filter Mesh

Product Details:
Place of Origin: HEBEI ,CHINA
Brand Name: R&K
Certification: MSDS,ROSH,SGS,ISO 9001
Model Number: R&K-Nylon mesh
Payment & Shipping Terms:
Minimum Order Quantity: 10 meters
Price: Negotiable
Packaging Details: 1.30-70m/roll in PVC bag 2 2-8 rolls per carton 3.waterproof bags outside 4.package belt strengthen
Delivery Time: 7~15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Meters per month
Detailed Product Description
Usage: Liquid Filter Length: 30-70m/roll
Weave Style: Plain Woven Nylon Mesh Technique: Woven
Feature: Corrosion Resistance Color: White
High Light:

plain weave nylon filter mesh


30m/roll nylon filter mesh


1.25m nylon filter mesh

Corrosion Resistance Food Grade Plain Weave Nylon Filter Mesh Custome Width

Product Introduction


Nylon net is a chemical fiber braided net made of chemical fibers such as nylon yarn, nylon yarn, polyester yarn, and nalon yarn. The nylon fiber has the function of high temperature resistance and alkali resistance, and the polyethylene has the effect of acid resistance. , Nylon mesh is the general term for these chemical fiber woven mesh.



Material:FDA food grade commercial nylon mesh

Mesh opening:5-1950 micron

Weave Style:Plain Weave

Thread Diameter:31-550 micron

Monofilament Style:Yes

Thickness:51-1100 micron

Hole Shape:square

Roll length:30-70m or customized

Roll width:1m, 1.25m, 2.5m, 2.95m or customized

Usage:liquid filter, air filter, dust filter

Type:filter mesh, filter cloth, mine sieving mesh, filter disc, filter cylinder


Product Application



1. Resistance to low temperature is conducive to enhancing its ability to resist environmental strain.

2. Abrasion resistance, which is helpful for adapting to occasions with high abrasion resistance requirements.

3. The antistatic property is beneficial to adapt to the requirements of mines and their mechanical applications.

4. The heat resistance is beneficial to adapt to the field of high temperature conditions such as automobile engines.


5. With the miniaturization of automobiles, the high-performance of electronic and electrical equipment, and the acceleration of the weight reduction of mechanical equipment, the demand for nylon will be greater and the requirements will be higher. Especially nylon as a structural material, modern equipment and products put forward higher requirements on its strength, heat resistance and cold resistance.


Product Features


1.Faster turnaround time from the screen room to the pressroom
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Three factories for manufacturing
8. Imported weaving machines from Switzerland and Italy



Product Specification


NL5/1500 5 13 500 1500 1000 308
NL6/1267 6 15 400 1267 840 228
NL7/1079 7 18 350 1079 640 209
NL8/900 8 20 350 900 645 232
NL9/861 9 24 250 861 460 145
NL10/750 10 25 250 750 530 148
NL12/533 12 30 300 533 495 256
NL14/514 14 35 200 514 380 135
NL16/425 16 40 200 425 400 155
NL16/375 16 40 250 375 420 240
NL17/388 17 42 200 388 380 160
NL18/366 18 45 220 366 400 207
NL20/300 20 50 200 300 375 190



Product Package


1. We always use poly bag for the goods which ship by air, so that customer can save freight free
2. Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping
3. There also have some customer request us to use the carton to packing their goods
4. We can according to customer's requirements




30m/Roll Plain Weave 1.25m Nylon Filter Mesh 0
