304 Materila 310s Materila Square Dutch Wire Mesh Stainless Steel Filter Screen

Large Image : 304 Materila 310s Materila Square Dutch Wire Mesh Stainless Steel Filter Screen

Product Details:

Place of Origin:	Hebei,China
Brand Name:	R&K
Certification:	ISO9001:2008,SGS,FDA
Model Number:	R&K-SS

Payment & Shipping Terms:

Minimum Order Quantity:	1m
Price:	negotiation
Packaging Details:	Packing by rolls or folded then plastic bags inside carton or other packages according to the customers' demand.
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union,Paypal,Trade assurance.Credit card.
Supply Ability:	2000 square meter per month

Contact Now

Detailed Product Description

Material:	304 ,316	Weave Type:	Plain Weave,Twill Weave,Dutch Weave
Mesh Count:	1-400mesh	Size:	As Requirements
Product Name:	304 316 Stainless Steel Square Dutch Welded Wire Mesh Tube For Filtering	Application:	Filtration
High Light:	ss304 Filter Tube , 1x1 Stainless Steel Filter Tube

304 Materila 310s Materila Square Dutch Wire Mesh Stainless Steel Filter Screen

The difference between 304 material and 310S material

Characteristics of 304 stainless steel: 304 stainless steel is the most widely used chromium-nickel stainless steel, with good corrosion resistance, heat resistance, low temperature strength and mechanical properties. It is corrosion resistant in the atmosphere. If it is an industrial atmosphere or a heavily polluted area, it needs to be cleaned in time to prevent corrosion.

310S stainless steel characteristics: 310S stainless steel is an austenitic chromium-nickel stainless steel, with good oxidation resistance and corrosion resistance. Because of the higher percentage of chromium and nickel, 310S has better creep strength and can continue to work at high temperatures. Has good high temperature resistance

Application of stainless steel wire mesh :

Used in mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries.

Specification of the stainless steel wire mesh:

Stainless steel mesh is classified according to species:

1. Stainless steel plain weave mesh.

2. Stainless steel twill mesh.

3. Five-shed stainless steel mesh.

4. Stainless steel punching net.

5. Stainless steel crimped wire mesh.

6. Stainless steel expanded metal mesh.

7. Stainless steel welded wire mesh.

Mesh/Inch	Wire Diameter		Aperture		Open Area	Weight (kg/Square meter)
Mesh/Inch	Inch	MM	Inch	MM	Open Area	Weight (kg/Square meter)
1*1	0.08	2.03	0.92	23.37	92	2
2*2	0.063	1.6	0.437	11.1	87.4	2.5
3*3	0.054	1.37	0.279	7.09	83.8	2.7
4*4	0.047	1.19	0.203	5.16	81.2	2.7
5*5	0.041	1.04	0.159	4.04	79.5	2.6
10*10	0.025	0.64	0.075	1.91	74.9	2
12*12	0.02	0.508	0.063	1.6	75.9	1.5
14*14	0.02	0.508	0.051	1.3	71.9	1.8
16*16	0.018	0.457	0.445	1.13	71.2	1.6
18*18	0.017	0.432	0.386	0.98	69.4	1.6
20*20	0.02	0.24	0.03	0.76	76	0.56
20*20	0.016	0.33	0.034	0.86	72.2	1.1
30*30	0.12	0.305	0.213	0.54	63.9	1.4
30*30	0.0094	0.24	0.243	0.62	72.1	0.84
40*40	0.01	0.254	0.015	0.38	59.9	1.3
50*50	0.0055	0.14	0.0145	0.368	72.4	0.48
60*60	0.0047	0.12	0.012	0.303	71.6	0.42
60*60	0.0059	0.15	0.0107	0.273	64.5	0.65
80*80	0.0055	0.14	0.0069	0.117	45.5	0.76
100*100	0.0045	0.114	0.0055	0.14	55.1	0.59
100*100	0.004	0.102	0.006	0.152	59.8	0.49
120*120	0.0028	0.07	0.0057	0.147	67.7	0.29
150*150	0.0024	0.06	0.0043	0.11	64.7	0.26
150*150	0.0028	0.07	0.0039	0.1	58.8	0.38
165*165	0.0019	0.05	0.0041	0.104	67.5	0.2
180*180	0.0019	0.05	0.0035	0.091	64.5	0.22
180*180	0.0024	0.06	0.0031	0.081	57.4	0.32
200*200	0.0019	0.05	0.003	0.077	60.6	0.24
200*200	0.0024	0.06	0.0026	0.067	52.7	0.35
250*250	0.0016	0.04	0.0024	0.0616	60.6	0.2
270*270	0.0016	0.04	0.0021	0.054	57.4	0.21
300*300	0.0016	0.04	0.0018	0.045	53.5	0.23
325*325	0.0014	0.035	0.0017	0.0432	55.3	0.2
400*400	0.0012	0.03	0.0013	0.0335	52.7	0.18
500*500	0.0009	0.025	0.001	0.0258	50.7	0.15
635*635	0.0007	0.018	0.0008	0.022	55	0.1
