Heat Resistance Large Loop Polyester Mesh Belt For Food Industry

Heat Resistance Large Loop Polyester Mesh Belt For Food Industry
Heat Resistance Large Loop Polyester Mesh Belt For Food Industry Heat Resistance Large Loop Polyester Mesh Belt For Food Industry Heat Resistance Large Loop Polyester Mesh Belt For Food Industry

Large Image :  Heat Resistance Large Loop Polyester Mesh Belt For Food Industry

Product Details:
Place of Origin: HEBEI ,CHINA
Brand Name: R&K
Certification: MSDS,ROSH,SGS,ISO 9001
Model Number: R&K-Polyester mesh belt
Payment & Shipping Terms:
Minimum Order Quantity: 10 meters
Price: Negotiable
Packaging Details: 1.We always use poly bag for the goods which ship by air, so that customer can save freight free. 2.Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping. 3.There also have some customer request us to use the
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Meters per month
Detailed Product Description
Material: 100% Polyester Surface: Smooth
Advantage: High Wear Resistance Color: White And Blue
Usage: Dryer And Filter Function: Paper Mill Dryer Belt
High Light:

Large Loop Polyester Mesh Belt

,

Food Industry Polyester Mesh Belt

,

waterproof polyester woven mesh belt

Heat Resistance 100% Polyester Large Loop Mesh Belt Polyester Dryer Belt For Food Industry



Product Description





Color:White,Blue,Red

Feature: Waterproof

Technics:Woven Mesh



Anti-static Screen Mesh is specially made in spiral weave of monofilament with filling metal wire to increase anti-static property. With the conductive metal fiber woven into the mesh belt, the polyester mesh screen can release the friction electrostatic occured during high speed operation of machine. Hence, it is called anti-static wire mesh. The anti-static polyester conveyor belts are used in drying pulp style paper-making, chemical fiber, continuous pre-press mesh belt, environmental protection, high density paper board making, rubber and other anti-static industries.





Product Application



1. Separation in solid and liquid to equip with filter press
2. conveyor belts filtration machine
3. Filter Leaf ,
4. Horizontal Rotating Pan Filter ,Vacuum filter
5. in Chemical industry ,Fertilizer industry
6. Sugar making ,
7. food and beverage ,metallurgy
8. Building ,Waste water dealing ,and so on .



Spiral belts are mainly used in filtration or separation applications for municipal projects for example waste water treatment, and various sludge belt press liquid filtration applications. Our products are suitable for most mechanical dewatering cases of various materials.



polyester spiral dryer belt is suitable for high-pressure pressfilter washer, horizontal belt washer, pulp-liquor separator and netting belt coal-washer.
polyester spiral dryer belt are extensively used for producing cardboard,kraft paper,corrugated paper,paper for train fare,single two-shed press-filter,instead of papermaking machine dry blanket,canvas,as well as apply to colliery,food and medicine as conveyor belts.
polyester spiral dryer belt are made with special first quality yarns in 100%polyester,every spiral link dryer fabric is heat-set granting a high degree of stability and long running life.



Product Features



Has the acid and alkali resistance, wear resistance, high temperature resistant, long service life.
With smooth surface, the tensile strength, permeability is good.
High heat transfer efficiency, for the user to save energy.
Install easy to use, interface without stain, strength can reach the normal mesh products.
Heat-resistance,high temperature resistance(180 degree).
High dimensional and diagonal stability,good air ventilation.
Filled or unfilled to achieved differing filtration characteristics.
Super heat with resin sealed edges for lasting,no marking,economical solution
Can be repaired easily on site



Material advantages



Advantages of our spiral belts are focusing on: strength, flat surface, good air permeability, stable property against heat and moisture, low thermal shrinking, less elongation at heat and a long lifespan.





Product Specification





Loop Weave Model Wire / Thread Diameter (mm) Thickness(mm) Weight(kg/m2) Air Permeability
(m3/m2h)
Warp Weft
Large Loop 4070B 0.9 1.1 3 1.7 20500+-1500
Large Loop 4070A 0.9 1.1 3 1.9 5250+-500
Medium Loop 3868B 0.7 0.9 2.5 1.4 18500+-1500
Medium Loop 3868A 0.7 0.9 2.5 1.7 4750+-500
Small Loop 3252B 0.5 0.7 1.9 1.1 15000+-1500
Small Loop 3252A 0.5 0.7 1.9 1.4 4000+-500





Heat Resistance Large Loop Polyester Mesh Belt For Food Industry 0
