100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing

Certification
Good quality Screen Printing Mesh for sales
Good quality Screen Printing Mesh for sales
I'm Online Chat Now

100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing

China 100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing supplier
100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing supplier 100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing supplier 100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing supplier 100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing supplier

Large Image :  100% Polyester Yellow Screen Printing Mesh Roll Heat Resistance For Cermics Printing

Product Details:

Place of Origin: Hebei,China
Brand Name: R&K
Certification: FDA
Model Number: R&K-M415

Payment & Shipping Terms:

Minimum Order Quantity: 50 Meters
Price: negotiation
Packaging Details: well packed for oversea shipment
Delivery Time: 5-15 days after you payment
Payment Terms: L/C,T/T,Western Union ,Paypal, Trade,assurance.
Supply Ability: 1000 Meter/Meters per Day
Contact Now
Detailed Product Description
Material: 100% Polyester Printing: Silk Screen Printing
Weave Type: Plain Colour: White,yellow
Length: 50 M/roll Mesh Count: 200-500mesh
Width: 1.27m Wire Diameter: 40-500um

100% Polyester Yellow Color Heat Resistance Silk Screen Printing Mesh For Cermics Printing





Description of polyester silk screen printing mesh:



Screen printing is used in a wide range of applications, decorative and industrial. In addition to the desired optical appearance, effect pigments for screen printing are subject to various requirements such as mechanical, washing or temperature resistance.

Specification





Mesh Count
Diameter
(Mesh/inch μm)
Mesh
Count
(Mesh
/Inch)
Weave Aperture
(μm)
Thread
Diameter
(μm)
Opening
(%)
Thickness(μm) Thickness
Tollerance
(+/- μm)
Theoretical
lnk(cm3/m2)
Weight
(g/m2)
6-400 15 1:1 1270 400 64 720 T
7-350 18 1:1 1078 350 64 640
8-300 20 1:1 950 300 58 550
10-250 25 1:1 750 250 56 620
12-250 30 1:1 583 250 49 450
12-150 30 1:1 683 150 67 300
13-150PW(SL) 33 1:1 619 150 64 300 14 128 60
16-200 40 1:1 425 200 46 400
20-80 50 1:1 420 80 71 120
20-150 50 1:1 350 150 49 260
21-80pw(S) 55 1:1 296 80 69 120 9 79 35
21-150PW(SL) 55 1:1 326 150 46 260 14 118 121
24-100PW(T) 60 1:1 316 100 57 136 11 65 81
28-140PW(SL) 70 1:1 217 140 40 195 13 76 125
32-55PW(S) 81 1:1 257 55 67 103 6 67 28
32-64PW(S) 81 1:1 248 64 63 95 6 56 32
32-100PW(T) 81 1:1 212 100 45 165 8 73 75
36-90PW(T) 92 1:1 183 90 44 150 8 65 68
39-55PW(S) 100 1:1 177 55 56 88 6 55 30
40-80PW(T) 103 1:1 166 80 44 133 7 59 60
43-80PW(T) 110 1:1 149 80 41 130 7 53 64
47-45PW(S) 120 1:1 166 45*2 61 80 6 42 40
47-55PW(S) 120 1:1 152 55 51 88 6 48 34
48-70PW(T) 122 1:1 133 70 41 115 6 47 55
53-45PW(S) 135 1:1 143 45*2 57 79 7 41 46
53-55PW(S) 135 1:1 133 55 50 86 6 42 40
54-64PW(T) 137 1:1 115 64 39 100 5 39 51
54-70(PW)HD 137 1:1 109 70 35 116 6 40 62
61-64PW(T) 155 1:1 90 64 31 101 5 30 58
64-55PW(S) 160 1:1 98 55 38 98 5 36 48
64-64PW(T) 160 1:1 85 64 30 115 6 34 61
68-55PW(S) 175 1:1 85 55 34 85 4 28 48
68-64PW(T) 175 1:1 78 64 28 105 5 30 65
72-48PW(S) 182 1:1 90 48 36 78 5 33 39
72-55PW(T) 182 1:1 85 55 30 90 5 27 51
77-48PW(S) 195 1:1 77 48 35 80 4 28 42
77-55PW(T) 195 1:1 67 55 27 88 4 24 55
80-48PW(T) 200 1:1 72 48 33 74 4 25 56
90-48PW(T) 230 1:1 56 48 25 78 4 19 50
100-40PW(T) 255 1:1 58 40 33 63 3 21 37
110-40PW(HD) 280 1:1 48 40 27 64 3 17 40
120-31PW(S) 305 1:1 49 31 35 49 3 17 26
120-34PW(T) 305 1:1 45 34 30 55 3 16 35
120-40PW(HD) 305 1:1 37 40 20 63 3 13 44
130-34PW(T) 330 1:1 40 34 27 55 3 15 37
140-31PW(S) 355 1:1 36 31 26 48 2 12 30
140-34PW(T) 355 1:1 31 34 20 53 3 10 39
140-34TW(T) 355 1:1 33 34 21 56 3 12 41
150-31PW(S) 380 1:1 32 31 23 49 3 11 32
150-34PW(T) 380 1:1 23 34 13 55 3 6.5 42
165-34PW(S) 420 1:1 23 31 15 48 2 7 36



Applications of polyester silk screen printing mesh:



1: Auto glass printing
Black mask on the front, side and back. Windows, heating mode, antenna (radio, GPS) and sun roof.
2: Glass container printing.
Perfume, cosmetics and beverage bottles are decorated by screen printing
3: Print a grid for ceramics
Polyester screen printing can be used to print challenging, intense colors and gorgeous decorations on ceramics, so it is widely used in the decoration of tableware, ceramic tiles, pottery or fine porcelain.
4: Printing net for textiles
Polyester screens transfer thick ink deposits and create special effects, making them the best process for printing high quality commercial apparel.
5: Print a CD/DVD grid
Polyester screen printing provides ink transparency, ink gloss, and a variety of decorative pattern options. The most important is the fast production cycle and the performance of the disc is not affected. So screen printing is an optimized printing process for CD and DVD decoration.
6: Printing glass mesh
Direct screen printing on articlis fopharmacy glassware, such as appliance name, measurement mark.
Printing glass decorations on the home
Microwave oven doors and ceramic hot plates / stoves and other equipment.



Advantabges



1: Acld and alkali resistance
2: Good permeability
3: Stable tensile
4: Long work time
5: Low elongation
6: Heat resistance
7: High temperature resistance
8: High corrosion resistance
