Stainless Steel Wire 304N Screen Printing Mesh Roll

Large Image : Stainless Steel Wire 304N Screen Printing Mesh Roll

Product Details:

Place of Origin:	Hebei,China
Brand Name:	R&K
Certification:	FDA
Model Number:	J110

Payment & Shipping Terms:

Minimum Order Quantity:	50 meters
Price:	negotiation
Packaging Details:	Waterproof,woven bags inside,carton or plywood case outside.
Delivery Time:	Within 8 work days
Payment Terms:	L/C，T/T，Western Union，Paypal，Trade assurance,Credit card
Supply Ability:	20000 square meter per month

Contact Now

Detailed Product Description

Product Name:	Stainless Steel Screen Printing Mesh Roll	Certification:	ISO,SGS
Application:	PCB,LCD,Electronic Component	Weave Style:	Plain Weave
Roll Width:	Standard Size 100/122/135/150/165cm	Roll Length:	Standard 30 Meters
High Light:	nylon mesh screen roll , silk screen roll

304N Stainless Steel Wire Mesh Screen Printing Mesh 200 Mesh 250 Mesh Roll

Description of stainless steel screen mesh:

Material	304N
Product Name	304N Stainless Steel Wire Mesh Screen Printing Mesh 200 Mesh 250 Mesh Roll
Mesh count	200 Mesh 250 Mesh
Wire diameter	35-50um
Roll length	standard 30 meters for one roll
Roll width	1.0m/1.22m/1/35m/1.50m/1.65m
Mesh Thickness	76-103um

Features of stainless steel screen mesh:

The stainless steel wire mesh is preservative!
The stainless steel wire mesh is wear-resistant and durable!
The stainless steel wire mesh is easy plastic processing, diversifying the possibilities of using stainless steel filters.
The stainless steel wire mesh is high finish, no surface treatment, easy maintenance.
The stainless steel wire mesh is standard size, uniform opening, precise control joint grade, etc.

Application of stainless steel screen mesh :

stainless steel filter wire mesh is used in petroleum,chemical industry,chemical fiber, food ,medicine,fertilizer,paper-making,airspace.

Specification of the stainless steel screen mesh:

Specification	Mesh/ inch	Wire Dia (μm)	Open area Ratio(%)	Apereture (μm)	Apereture (μm)	Calendered Thickness (μm)	Theoretical lnk(cm^/m^)
18018050	180	50	42	91	98-104	As order	41.7
20020040	200	40	46.9	87	82-84	As order	43
20020050	200	50	37	77	98-103	As order	42
23023035	230	35	46.7	75	72-76	50-67	37
25025040	250	40	36.8	62	82-86	50-80	34
25025030	250	30	49.7	72	64-68	40-58	30
25025035	250	35	43	67	76-78	57-70	32
27027035	270	35	39.4	59	76-80	58-70	30
30030030	300	30	41.7	55	66-68	4-59	28
32532530	325	30	38	48	66-68	45-60	24
32532528	325	28	41.2	50	63-64	40-56	26.4
32532523	325	23	49.8	55	49-53	37-41	25.4
35035035	350	25	43	48	52-54	41-50	18.7
40040023	400	23	40.7	41	50-54	35-48	19
40040018	400	18	51.3	46	36-40	28-30	20
50050018	500	18	41.7	33	36-40	23-29	15.3
