SS 314 plain weave stainless steel Dutch woven wire mesh filter belt
Description of stainless steel Dutch woven wire mesh
Dutch wire mesh, one of the most popular thin mesh screens, with a mesh size of 1 x 1 to 500 x 500, a wire diameter of 0.025 mm to 2.03 mm (0.001 inch to 0.08 inch) and a hole diameter of 0.0254 mm to 23.37mm (0.001 inches to 0.92 inches). As the wire diameter becomes thinner, the aperture will be larger.
Application of 60 um stainless steel Dutch wire mesh
Dutch wire mesh has endless applications in industry, commerce and decoration. Such as filters, sieves, separators, filters, baskets, gas diffusion, drying, car grille mesh, vents, building and construction nets, craft paper, decorative nets, fan hoods, filter liquids and gases, fireplace screens, food Dry, basic ventilation net, gutter protection net, high transparent net, hydraulic filter, insect net, lampshade, oil filter, pest control, safety, separation of fuel from water
Feature of the stainless steel Dutch wire mesh
►Better filtration performance.
►Higher tensile strength.
►Can be used to filter ultra-fine products.
►The structure is more stable.
Parameters of stainless steel Dutch mesh
|
plain weave Dutch mesh
|
|
Number
|
Mesh(warpxweft)
|
Wire diameter
(warpxweft)
|
Aperture
(um)
|
Weight
(kg/m2)
|
|
32#
|
8 x 62
|
0.63mm x 0.45mm
|
300
|
5.42
|
|
40#
|
10 x 79
|
0.50mm x 0.355mm
|
250
|
3.16
|
|
48#
|
12 x 64
|
0.58mm x 0.40mm
|
280
|
2.9
|
|
55#
|
14 x 88
|
0.40mm x 0.30mm
|
180
|
2.54
|
|
76#
|
19 x 140
|
0.315mm x 0.20mm
|
140
|
1.88
|
|
80#
|
20 x 300
|
0.35mm x 0.20mm
|
-
|
3.6
|
|
95#
|
24 x 110
|
0.355mm x 0.25mm
|
120
|
2.45
|
|
100#
|
25 x 140
|
0.28mm x 0.20mm
|
100
|
1.95
|
|
120#
|
30 x 150
|
0.25mm x 0.18mm
|
80
|
1.68
|
|
140#
|
35 x 175
|
0.224mm x 0.16mm
|
71
|
1.52
|
|
160#
|
40 x 200
|
0.20mm x 0.14mm
|
60
|
1.40
|
|
180#
|
45 x 250
|
0.16mm x 0.112mm
|
56
|
1.09
|
|
200#
|
50 x 250
|
0.14mm x 0.11mm
|
53
|
1.04
|
|
220#
|
55.5 x 280
|
0.14mm x 0.10mm
|
50
|
0.92
|
|
240#
|
65 x 330
|
0.11mm x 0.08mm
|
36
|
0.71
|
|
280#(1)
|
70 x 350
|
0.11mm x 0.08mm
|
35
|
0.72
|
|
280#(2)
|
70 x 385
|
0.11mm x 0.07mm
|
32
|
0.75
|
|
300#
|
78 x 700
|
0.11mm x 0.08mm
|
30
|
1.39
|
|
315#(1)
|
80 x 400
|
0.10mm x 0.065mm
|
40
|
0.62
|
|
315#(2)
|
80 x 600
|
0.10mm x 0.06mm
|
-
|
0.74
|
|
315#(3)
|
80 x 800
|
0.15mm x 0.04mm
|
-
|
0.77
|
|
320#
|
81 x 780
|
0.10mm x 0.07mm
|
30
|
1.22
|
|
354#
|
90 x 550
|
0.12mm x 0.05
|
-
|
0.667
|
|
Width:1m-1.6m
|
