High strength 304 material plain weave stainless steel dutch woven wire mesh
Description of stainless steel Dutch woven wire mesh
Stainless steel Dutch screens have different warp and weft numbers and diameters: more wefts and thicker warp threads. It is divided into plain weave and twill Dutch weave.
Dutch woven mesh can filter a variety of materials under acid, alkali and strong pressure. It is also widely used in aerospace, metallurgy, chemical and other industries. Fuel filters and vacuum filters are also important functions.
Application of stainless steel Dutch wire mesh
Dutch wire mesh has endless applications in industry, commerce and decoration. Such as filters, sieves, separators, filters, baskets, gas diffusion, drying, car grill nets, vents, building and construction nets, craft paper, decorative nets, fan hoods, filtering liquids and gases, fireplace screens, food Dry, basic ventilation net, gutter protection net, high transparent net, hydraulic filter, insect net, lampshade, oil filter, pest control, safety, separation of fuel from water
Feature of the stainless steel Dutch wire mesh
For filters or sieves, such as fuel filters, vacuum filters, cast film filters, sewage treatment;
Serving petroleum, aerospace, metallurgy, food, pharmaceutical and other industries;
Conveyor belts for washing machines, dryers and sludge presses.
Parameters of stainless steel Dutch mesh
|
Plain weave Dutch mesh
|
|
Number
|
Mesh(warpxweft)
|
Wire diameter
(warpxweft)
|
Aperture
(um)
|
Weight
(kg/m2)
|
|
32#
|
8 x 62
|
0.63mm x 0.45mm
|
300
|
5.42
|
|
40#
|
10 x 79
|
0.50mm x 0.355mm
|
250
|
3.16
|
|
48#
|
12 x 64
|
0.58mm x 0.40mm
|
280
|
2.9
|
|
55#
|
14 x 88
|
0.40mm x 0.30mm
|
180
|
2.54
|
|
76#
|
19 x 140
|
0.315mm x 0.20mm
|
140
|
1.88
|
|
80#
|
20 x 300
|
0.35mm x 0.20mm
|
-
|
3.6
|
|
95#
|
24 x 110
|
0.355mm x 0.25mm
|
120
|
2.45
|
|
100#
|
25 x 140
|
0.28mm x 0.20mm
|
100
|
1.95
|
|
120#
|
30 x 150
|
0.25mm x 0.18mm
|
80
|
1.68
|
|
140#
|
35 x 175
|
0.224mm x 0.16mm
|
71
|
1.52
|
|
160#
|
40 x 200
|
0.20mm x 0.14mm
|
60
|
1.40
|
|
180#
|
45 x 250
|
0.16mm x 0.112mm
|
56
|
1.09
|
|
200#
|
50 x 250
|
0.14mm x 0.11mm
|
53
|
1.04
|
|
220#
|
55.5 x 280
|
0.14mm x 0.10mm
|
50
|
0.92
|
|
240#
|
65 x 330
|
0.11mm x 0.08mm
|
36
|
0.71
|
|
280#(1)
|
70 x 350
|
0.11mm x 0.08mm
|
35
|
0.72
|
|
280#(2)
|
70 x 385
|
0.11mm x 0.07mm
|
32
|
0.75
|
|
300#
|
78 x 700
|
0.11mm x 0.08mm
|
30
|
1.39
|
|
315#(1)
|
80 x 400
|
0.10mm x 0.065mm
|
40
|
0.62
|
|
315#(2)
|
80 x 600
|
0.10mm x 0.06mm
|
-
|
0.74
|
|
315#(3)
|
80 x 800
|
0.15mm x 0.04mm
|
-
|
0.77
|
|
320#
|
81 x 780
|
0.10mm x 0.07mm
|
30
|
1.22
|
|
354#
|
90 x 550
|
0.12mm x 0.05
|
-
|
0.667
|
|
Width:1m-1.6m
|
