Product Details:
Payment & Shipping Terms:
|
Material: | 304 Stainless Steel | Filter Rating: | 1 - 200 Um |
---|---|---|---|
Technique: | Woven | Color: | Silver / Black |
Appication: | Filter | Weave Style: | Plain |
High Light: | round wire mesh screen,sintered stainless steel sheet |
Stainless steel sintered mesh for filtering high temperature materials
Product Description
What is a sintered mesh?
The sintered web is made from one or more layers of woven wire mesh by a "sintering" process. The single layer woven wire mesh is first evenly flattened to ensure good contact at the intersection of the wires. The single or multiple layers of the calendered web are then laminated under mechanical pressure in a high temperature furnace by a special clamp filled with a proprietary embedded gas and the temperature is raised to the extent that sintering (diffusion bonding) occurs. After controlling the cooling process, the mesh becomes more rigid because all the contact points of the individual wires are bonded to each other.
Sintering improves the properties of the woven wire mesh by a combination of heat and pressure. The sintered mesh may be a single layer or a plurality of layers, and a layer of perforated metal may be added to strengthen the entire structure according to filtration requirements. More importantly, the sintered mesh can be cut, welded, pleated, rolled into other shapes such as discs, plates, ink cartridges, and tapered.
Compared with the traditional wire mesh, the sintered mesh has outstanding advantages, high mechanical strength, high permeability, reduced pressure, wide filter range and easy backwashing. Although the cost seems to be higher than the traditional filter, its long service life and excellent performance have gained more popularity and obvious advantages.
Our main products include
Five-layer sintered mesh
Sintered mesh laminate
Sintered mesh with perforated metal
Sintered metal filter
Sintered metal filter disk
Folded sintered mesh filter
Sintered cone filter
Sintered metal fiber felt.
Product Application
• High viscosity liquid filtration, such as polymers and adhesives
• Hot fluid filtration
• Oil filtration, such as lubricating oil and turbine oil
• Fluid food filtration, if juice, cooking oil and vinegar
• Dewatering of sludge, food, etc.
Product Parameters
Note: This list for a reference, not for the complete list.
Nomin al filter rating |
structure prodextive layer+control layer +dispersion layer+ reinforce layer+ reinforce layer |
Thickness (mm) | air perm eabilit | Bubble pressure (mm) | weight (kg/m2) |
porosity (%) |
1 | 100+400*2800+100+12*64+64 | 1.7 | 1.81 | 360-600 | 5 layer 8.4 | 40% |
5 | 100+200*1400+100+12*64+64 | 1.7 | 2.42 | 260-550 | 6 layer 14.4 | 40% |
20 | 100+165*800+100+12*64+64* | 1.7 | 4.5 | 170-450 | 40% | |
200 | 40+80+40+20+40+80+40 | 2 | 26 | 50-150 | 40% |
