50-95A customizable size high temperature resistant 100% polyurethane screen printing squeegee
Product Introduction
Squeegee is an adhesive strip used in the screen printing process, and is also generally called glue scraping. Most of them are made of PU material. The rubber scraper has good solvent resistance and wear resistance. There are many varieties, and there are a variety of hardness, shape and size to choose from. Depending on the characteristics of the screen-printed substrate, the accuracy requirements of the printed pattern, and the printing method, squeegees of different hardness and different cross-sectional shapes can be selected.
How to choose
The hardness of the squeegee specifically refers to the hardness of its surface. It is often expressed in Shore Hardness: 55 degrees, 60 degrees, 65 degrees, 70 degrees, 75 degrees, 80 degrees, and 85 degrees. The cross-sectional shape generally has several types such as right angle type, sharp angle type and arc type. Detailed specifications are: 25 * 5mm, 35 * 5mm, 40 * 7mm, 50 * 7mm, 50 * 9mm, 50 * 8mm, 30 * 8mm, 35 * 8mm, 30 * 5mm, 35 * 7m m, 35 * 9mm, 50 * 5mm 45 * 8mm 25 * 7mm 50 * 9 round mouth 50 * 10mm slot 50 * 9.5mm 45 * 8 slot 50 * 7 three layers 50 * 9 three layers
Product Specification
| Color |
Hardness |
shore A |
Application |
| Green |
Medium |
70-75 |
Suitable for various
of mesh screen cloth,
various of ink and various of the prints. |
| Red |
Soft |
50-65 |
Suitable for the low mesh screen cloth ,low viscosity ink,irregular surface of the printing. |
| Blue |
Hard |
80-85 |
Suitable for high pressure,
high viscosity ink,the fine print of the printing |
| White |
Super hard |
90-95 |
Suitable for high pressure,
high viscosity ink,the fine print
of the printing |
Green/White/
Green |
Triple
medium |
75/90/75 |
Suitable for various of mesh screen cloth,various of ink and various of the prints. |
| Red/White/Red |
Soft
medium |
65/90/65 |
Suitable for the low mesh screen cloth ,low viscosity ink,irregular
surface of the printing.
|
Product Features
In screen printing, the function of the squeegee mainly has the following four aspects:
1. Transfer the ink to the substrate through the screen.
2. Scrape off excess ink from the screen.
3. Keep the screen in contact with the substrate line.
4. It can print substrates with different shapes.
Product performance
1. High Abrasion
2. Super Solvent
3. High Tolerance
4. High Cut Resistance
5. Cut Customization
6. Size Customization
FAQ
The hardness of the squeegee specifically refers to the hardness of its surface. It is often expressed in Shore Hardness: 55 degrees, 60 degrees, 65 degrees, 70 degrees, 75 degrees, 80 degrees, and 85 degrees. The cross-sectional shape generally has several types such as right angle type, sharp angle type and arc type. Detailed specifications are: 25 * 5mm, 35 * 5mm, 40 * 7mm, 50 * 7mm, 50 * 9mm, 50 * 8mm, 30 * 8mm, 35 * 8mm, 30 * 5mm, 35 * 7m m, 35 * 9mm, 50 * 5mm 45 * 8mm 25 * 7mm 50 * 9 round mouth 50 * 10mm slot 50 * 9.5mm 45 * 8 slot 50 * 7 three layers 50 * 9 three layers
