Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: FDA
Model Number: R&K-He 8865
Payment & Shipping Terms:
Minimum Order Quantity: 50meters
Price: negotiation
Packaging Details: plastic bag inside, carton case outside,5-10rolls in one carton
Delivery Time: 5-8 days
Payment Terms: L/C,T/T,Western Union,Paypal,Trade,Assurance
Supply Ability: 3000 meters per week
Detailed Product Description
Feature: Low Elasticity Application: Textile Screen Printing Mesh
Mesh Count: 280 Mesh Color: White
Width: 1 M 1.27 M 1.45 M 1.65 M Thread Diameter: 40um
Length: 50 M Per Roll Package: Roll Package
High Light:

polyester screen mesh

,

polypropylene filter mesh

280 Mesh Polyester White Mesh Textile Screen Printing Application Low Elasticity





Description



Our polyester printing net has the characteristics of high tension, low elongation, uniform mesh, wear and corrosion resistance, high stability, high precision, dustproof and antistatic, good silk screen performance, etc. It is widely used in textile printing plate making and glass ceramics. , flower paper signs, touch screen circuit boards, membrane switches, aerospace, food, medical, filtration and other industries. And with its high-quality products and services, it has won unanimous praise from domestic and foreign customers. The products are exported to Southeast Asia, Middle East, Europe and America.





Features of polyester screen printing mesh:



1, the mesh is even, the mesh surface is flat
2, standard mesh, accurate filter value
3, super tension, low elongation, easy to use and flexible
4. Ultra-precision mesh makes the printing effect more delicate and beautiful.
5, strong acid, alkali and corrosion resistance



Application  of polyester screen printing mesh:



Polyester Screen Printing Mesh is widely used in electronic circuit board, fine ceramics, colored glass, textile, printing and dyeing, various filtration industries and petrochemical industry



Specification of polyester screen printing mesh



COUNT (INCH) COUNT (CM) DIAMETER (UM) OPEPING (UM) OPEN AREA(%) THICKNESS(UM) VOLUME (CM³/CM²) MAX TEN SION(N/CM)
15 6 400 1270 64 720 460 30-60
18 7 350 1078 64 640 410 30-60
20 8 300 950 58 550 319 30-60
25 10 250 750 56 620 347 30-60
30 12 250 583 49 450 220 30-60
30 12 150 683 67 300 201 30-60
40 16 200 425 46 400 184 30-60
50 20 80 420 71 120 85 35-37
50 20 150 350 49 260 127 30-60
60 24 100 316 58 136 78 35-40
60 24 120 297 50 240 120 35-60
73 29 120 225 43 240 103 35-60
80 32 100 212 46 200 92 35-40
80 32 64 248 63 95 59 30-34
85 34 100 195 44 221 97 35-40
90 36 100 178 41 216 88 35-40
100 39 80 176 47 150 70 35-37
100 39 55 200 61 88 53 25-30
110 43 80 153 43 130 56 35-37
120 47 55 158 55 88 48 25-30
120 47 71 142 44 135 59 30-34
135 53 55 133 50 86 43 25-30
135 53 64 125 44 100 44 26-31
150 59 64 105 38 100 38 26-31
160 64 55 101 42 98 41 25-30
160 64 64 92 35 120 42 30-34
180 72 48 91 43 78 66 27-29
180 72 55 84 37 100 37 25-30
200 80 48 77 38 74 28 27-29
195 77 55 75 33 105 34 25-30
230 90 48 63 33 85 28 27-29
250 100 40 60 36 70 25 20-24
280 110 40 51 31 85 26 20-24
305 120 40 43 27 68 18 20-24
355 140 34 37 27 58 15 22-24
380 150 31 36 29 46 13 21-23
420 165 31 30 24 46 11 21-23
460 180 27 28 26 56 14 20-22





Packing of polyester screen printing mesh:

  • mesh rolls in a pp bag
  • 2-12rolls per cartons
  • waterproof bags outside
  • package belt strengthen
